ALPHA WIRE SW5CL008 Spiral Wrap Tubing
The SW5 CL008 spiral wrap tubing crafted from polyethylene simplifies wire harnessing, cabling, and bundling in industrial, defense, military, and aerospace applications. It features an outside diameter of 0.750 inches and an inside diameter of 0.620 inches, with a wall thickness of 0.065 inches. Designed with a right-hand pitch, it is flexible and easy to install, providing a secure, tight fit around wires without tools. The tubing includes openings for breakouts and tap-off connections, with a tensile strength of 1800 PSI, ensuring durability and reliable performance.
ALPHA WIRE SW5CL008 Spiral Wrap Tubing Specifications:
- Material: Polyethylene
- Color: Natural
- Flammability: Not Rated
- External Diameter: 0.750" +/- 0.025"
- Internal Diameter: 0.620" Nominal
- Wall Thickness: 0.065" Nominal
- Pitch: 0.750" Nominal
- Pitch Direction: Right Hand
- Temperature Rating: -60°C to +88°C
- Tensile Strength: 1800 PSI
- Applicable Standards: ASTM 1248-65T Type 1 Class A Grade 3, DSSC CID A-A59602 Type 1 Class1, MIL-I-631D Type A Form U, MIL-P-21922B
- Compliance: EU RoHS2 2011/65/EU, REACH EC 1907/2006
Buy the AlphaWire Series Spiral Wrap Tubing: SW5CL008
Order AlphaWire SW5CL008 spiral wrap tubing online today and enjoy a reliable, flexible solution for wire bundling in industrial, military, and aerospace applications. Crafted from durable polyethylene, this tubing offers a 0.750 inch outside diameter, right-hand pitch, and breakout openings for easy wire management. With a tensile strength of 1800 PSI, it ensures secure protection around wires even in harsh environments. Easy to install without tools, it provides a neat, organized appearance for complex wiring systems, backed by high-quality standards and compliance with international regulations.
Buy AlphaWire SW5CL008 now and experience reliable, flexible wire protection with high tensile strength for demanding industrial and aerospace environments.
Frequently Asked Questions
Where can I buy ALPHA WIRE SW5CL008?
You can click on the BUY or RFQ button to purchase SW5CL008 from an authorized ALPHA WIRE distributor.
How do I troubleshoot issues or seek technical support for part SW5CL008?
You can download the SW5CL008 datasheet or visit the ALPHA WIRE website for support.
Who is the manufacturer of SW5CL008?
ALPHA WIRE
