AMPERITE 12DAAHDFA Dual Rate Flasher
This dual rate flasher is designed for 12 V DC systems, featuring adjustable flash rates with two timing periods ranging from 0.1 to 10 seconds each. It is mounted via a plug-in 8-pin octal connector and can handle an output current of up to 10 amps. The device offers precise timing adjustments using two knob-operated potentiometers for both the Off and On times, with a fixed or adjustable range from 0.1 seconds to 240 hours. Suitable for industrial applications, it features a durable plastic enclosure, silver cadmium oxide contacts rated up to 15A at 120V AC, and is built for long-term reliability and easy installation.
AMPERITE 12DAAHDFA Dual Rate Flasher Specifications:
- Input Voltage: 12V DC, 24V DC, 48V DC, 110V DC
- Output Current Rating: 10A
- Contact Material: Silver - Cadmium Oxide
- Contact Rating: 15A @ 120V AC Resistive
- Timing Range: 0.1 seconds to 240 hours adjustable with two potentiometers
- Timing Tolerance: + 5%; 1% units available at extra cost, adjustable units -0 to +10%
- Repeatability: + 1%
- Release Time: 60 ms typical, 100 ms maximum
- Environmental Operating Range: -45°C to +70°C
- Termination: 8 pin Octal or 11-pin spade terminals
- Enclosure: White plastic case
- Dimensions: Approximate, suitable for DIN mounting
- Weight: 4 oz (114 g)
Buy the Buy Amperite Dual Rate Flasher Part Number 12DAAHDFA Online
Experience reliable flashing performance with the Amperite dual rate flasher designed for 12V DC systems. Featuring adjustable timing from 0.1 to 10 seconds, this compact device is easy to install with plug-in octal connectors. It handles currents up to 10 amps and offers precise control for industrial or automotive use. Built with durable materials, it withstands harsh environments and provides long-term operation. Perfect for alert signals, warning lights, or creating custom flash cycles with adjustable Off and On times for versatile applications.
Get Amperite durable 12DAAHDFA dual rate flasher today—built for precise timing and long-lasting durability suitable for industrial and automotive applications.
Frequently Asked Questions
Where can I buy AMPERITE 12DAAHDFA?
You can click on the BUY or RFQ button to purchase 12DAAHDFA from an authorized AMPERITE distributor.
How do I troubleshoot issues or seek technical support for part 12DAAHDFA?
You can download the 12DAAHDFA datasheet or visit the AMPERITE website for support.
Who is the manufacturer of 12DAAHDFA?
AMPERITE
