AMPHENOL COMMUNICATIONS SOLUTIONS 57202G5206ALF Industrial Card Connector
The Minitek II connector is a dual-row, vertical or right-angle card connector designed for 2.0mm center spacing, made with glass-filled PBT or PCT housing and phosphor bronze terminals. It features gold-plated contacts, UL 94V-0 flammability rating, and ratings of 200V AC/DC and 2A. Suitable for high-temperature environments up to 125°C, it complies with MIL-STD and JIS standards, offering excellent electrical performance, mechanical durability, and resistance to humidity, salt spray, thermal shock, vibration, and H₂S exposure, making it ideal for rugged industrial applications.
AMPHENOL COMMUNICATIONS SOLUTIONS 57202G5206ALF Industrial Card Connector Specifications:
- Material: Phosphor Bronze, Glass-filled PBT or PCT housing
- Finish: Gold-plated contacts, UL 94V-0 flammability rated
- Voltage Rating: 200V AC/DC
- Current Rating: 2A
- Operating Temperature: -55°C to 125°C (PCT); -40°C to 105°C (Nylon 6,6 & PBT)
- Contact Resistance: ≤ 20mΩ before test, ≤ 25mΩ after
- Insulation Resistance: ≥ 100MΩ at 500V DC
- Dielectric Withstanding Voltage: 650V AC/1 min
- Temperature Rise: ≤ 30°C at 2A
- Vibration: MIL-STD-202, Method 201A, 2-55-10 Hz, amplitude 1.5mm, 6 hours
- Salt Spray: 48 hours, no oxidation or damage
- Thermal Shock: 5 cycles, -55°C to 105°C, no damage
- Humidity: 96 hours at 90-95%, no cracking or swelling
- Mechanical: Contact retention > 0.5kg, post retention > 1kg, In/Unmating force complies
- Solderability: ≥ 90% coverage, MIL-STD-202, Method 208C
- Solder Heat Resistance: No damage at 260°C for 5 sec
Buy the Minitek II 57202G5206ALF – Reliable Industrial Card Connector for Rugged Applications
Purchase the Minitek II industrial card connector online today—designed with durability, excellent electrical performance, and environmental resistance. Its 2.0mm pitch and gold-plated contacts ensure reliable connections even in harsh conditions. Ideal for rugged industrial applications requiring high temperatures, vibration resistance, humidity tolerance, and compliance with rigorous standards like MIL-STD-202 and JIS. Easy to install with excellent stability, this connector guarantees long-term durability, making it the perfect choice for demanding electronic assemblies and industrial equipment.
Get Minitek II 57202G5206ALF today—built for precision, high-temperature resilience, and long-lasting durability in industrial environments.
Frequently Asked Questions
Where can I buy AMPHENOL COMMUNICATIONS SOLUTIONS 57202G5206ALF?
You can click on the BUY or RFQ button to purchase 57202G5206ALF from an authorized AMPHENOL COMMUNICATIONS SOLUTIONS distributor.
How do I troubleshoot issues or seek technical support for part 57202G5206ALF?
You can download the 57202G5206ALF datasheet or visit the AMPHENOL COMMUNICATIONS SOLUTIONS website for support.
Who is the manufacturer of 57202G5206ALF?
AMPHENOL COMMUNICATIONS SOLUTIONS
