AMPHENOL COMMUNICATIONS SOLUTIONS 5740500 Miniature D Ribbon Connector
The 57-40500 is a 50-position miniature D ribbon connector designed for top cable entry, featuring spring latch receptacles for quick electrical connection. It utilizes reliable ribbon contacts with gold over nickel plating on a copper alloy base, ensuring durability and easy mating. The connector includes a zinc-plated steel shell with corrosion-resistant chromate finish for EMI and RFI shielding. Contacts are recessed within the body to prevent damage, and are color-coded for wiring identification. Rated for 5A per contact, it operates from -55°C to +105°C, UL approved, ideal for communications, networking, medical devices, sensors, and instrumentation.
AMPHENOL COMMUNICATIONS SOLUTIONS 5740500 Miniature D Ribbon Connector Specifications:
- Contact Type: Solder cup for 22-30 AWG solid and stranded wires
- Dielectric Material: Viton (per MIL-M-14F, UL-94VO)
- Contact Material: Copper alloy with 20 micro-inches gold flash and 50 micro-inches nickel underplating
- Shell Material: Zinc-plated steel with clear chromate coating
- Current Capacity: 5 amps per contact
- Voltage Rating: 700V DC at sea level, 200V DC at 70,000 feet
- Insulation Resistance: >5000 M ohms
- Dielectric Withstanding Voltage: 1200 VAC (RMS) at sea level
- Operating Temperature Range: -55°C to +105°C
- Mating Force: Refer to table in datasheet
- Contact Retention Force: Max 2 lbs
- Durability: Minimum 250 cycles
- Vibration Resistance: No interruptions <1 microsecond
- Connector Type: Receptacle with spring latch for quick connection
- Design: 50-pin miniature D ribbon, top cable entry, color-coded contacts
- Shielding: Metal shell for EMI/RFI protection
Buy the Reliable connector 5740500 – Top Cable Entry Miniature D Ribbon for Industrial Applications
Discover the dependable Amphenol 5740500 miniature D ribbon connector, offering easy top cable entry, gold-plated contacts, robust steel shell, and reliable performance. Perfect for communications, networking, medical devices, and instrumentation, it ensures optimal electrical contact with a current capacity of 5A per contact. With a broad operating temperature range of -55°C to +105°C and UL approval, this connector guarantees durability, EMI/RFI shielding, and easy wiring identification. Ideal for professionals requiring secure and efficient connectivity solutions in demanding environments.
Order your Amphenol Series5740500 connector today and ensure reliable and easy electrical connections for your professional projects involving communication and instrumentation.
Frequently Asked Questions
Where can I buy AMPHENOL COMMUNICATIONS SOLUTIONS 5740500?
You can click on the BUY or RFQ button to purchase 5740500 from an authorized AMPHENOL COMMUNICATIONS SOLUTIONS distributor.
How do I troubleshoot issues or seek technical support for part 5740500?
You can download the 5740500 datasheet or visit the AMPHENOL COMMUNICATIONS SOLUTIONS website for support.
Who is the manufacturer of 5740500?
AMPHENOL COMMUNICATIONS SOLUTIONS
