AMPHENOL COMMUNICATIONS SOLUTIONS 66951010LF Wire-to-Board Connector
The product is a wire-to-board connector system designed for reliable electrical connections in various electronic applications, featuring dual-beam contacts for durability, low insertion force, and stackability. Made with high-temperature thermoplastic housing rated UL94V-0, with gold or tin plating over nickel, it supports up to 3A per contact, with insulation resistance of at least 1x 10^6 MQ. Operable from -65°C to +125°C, it offers 200 mating cycles with robust mechanical and environmental performance, suitable for low profile and high-density configurations in modern electronic assemblies.
AMPHENOL COMMUNICATIONS SOLUTIONS 66951010LF Wire-to-Board Connector Specifications:
- Housing: High temperature thermoplastic, UL94V-0
- Material: Phosphor-bronze pins, copper alloy contacts
- Plating: Gold or tin over 1.27μm nickel
- Current rating: 3A DC max per contact
- Insulation resistance: 1x 10^6 MQ min.
- Contact resistance: 15MQ max. initial, 20MQ max. after tests
- Dielectric withstanding voltage: 1000V RMS
- Operating temperature: -65°C to +125°C
- Mating cycles: 200
- Insertion force: 1.50 N max per gold contact
- Withdrawal force: 0.30 N min per gold contact
- Insertion depth: 3.6mm to 6.7mm, depending on series
- RoHS compliant, CE certified
Buy the Buy FCI DUBOX Wire-to-Board Connectors Part Number 66951010LF Online
Explore the advanced FCI DUBOX wire-to-board connector with dual-beam contacts, supporting up to 3A per contact, made with high-temperature thermoplastic and gold or tin plating. Designed for reliability, it offers 200 mating cycles, excellent environmental resistance, and low insertion force. Ideal for compact and high-density electronic assemblies, this connector ensures secure and durable electrical connections. Purchase online today to enhance your electronic design with a proven, industry-standard connector built for long-lasting performance and efficiency.
Get FCI DUBOX 66951010LF today—built for precision and long-lasting durability in electronic connections.
Frequently Asked Questions
Where can I buy AMPHENOL COMMUNICATIONS SOLUTIONS 66951010LF?
You can click on the BUY or RFQ button to purchase 66951010LF from an authorized AMPHENOL COMMUNICATIONS SOLUTIONS distributor.
How do I troubleshoot issues or seek technical support for part 66951010LF?
You can download the 66951010LF datasheet or visit the AMPHENOL COMMUNICATIONS SOLUTIONS website for support.
Who is the manufacturer of 66951010LF?
AMPHENOL COMMUNICATIONS SOLUTIONS
