AMPHENOL COMMUNICATIONS SOLUTIONS 57202G5203ALF High-Density Card Connector
Minitek II connector is a versatile double-row vertical card connector designed for high-density applications on 2.0mm center-to-center holes, available in vertical and right-angle configurations. Constructed using high-quality materials such as phosphor bronze for terminals, glass-filled PBT and PCT for housing, and nylon for header bodies, it ensures excellent durability, flammability resistance (UL 94V-0), and reliable electrical performance. It supports rated voltages of 200V and currents up to 2A, with operating temperatures from -40°C to 125°C. Suitable for a broad range of electronic assemblies requiring robust connectivity, high-temperature endurance, and environmental resilience.
AMPHENOL COMMUNICATIONS SOLUTIONS 57202G5203ALF High-Density Card Connector Specifications:
- Terminal Material: Phosphor Bronze with nickel and gold or palladium plating
- Housing Material: Glass-filled PBT and PCT, UL 94V-0 flammability rated
- Header Material: Phosphor Bronze and Glass-filled Nylon 6,6
- Contact Resistance: ≤20mΩ before test, ≤25mΩ after testing
- Rated Voltage: 200V AC/DC
- Rated Current: 2A AC/DC
- Operating Temperature Range: -40°C to 125°C (PCT), -40°C to 105°C (Nylon 6,6)
- Temperature Rise: ≤30°C at 2A current
- Humidity Resistance: No damage after 96 hours at 90-95% RH
- Salt Spray Resistance: No oxidation or damage after 48 hours in salt fog
- Vibration Resistance: No damage or discontinuity after MIL-STD-202, Method 201A test
- Mechanical Retention Force: ≥0.5kg per contact
- Durability: ≥100 mating cycles with resistance ≤25mΩ
- Solderability: ≥90% of surface dipped in solder bath, 60-40 tin-lead, 230°C
- Solder-Heat Resistance: No physical damage at 260°C immersion
Buy the Minitek II Series Connector: 57202G5203ALF
Order the Minitek II high-density card connector 57202G5203ALF online today and enjoy fast delivery, proven quality, and excellent electrical performance. Designed for demanding electronic applications, this connector offers superior durability, high-temperature endurance, and environmental resistance. Perfect for compact device assemblies requiring secure connections with minimal space. Trust our online store for competitive prices, detailed product specifications, and expert support to meet your project needs efficiently. Secure your supply of this reliable connector now and ensure optimal device performance.
Buy Minitek II connector 57202G5203ALF now and experience unmatched durability, high-temperature resilience, and reliable electronic connectivity.
Frequently Asked Questions
Where can I buy AMPHENOL COMMUNICATIONS SOLUTIONS 57202G5203ALF?
You can click on the BUY or RFQ button to purchase 57202G5203ALF from an authorized AMPHENOL COMMUNICATIONS SOLUTIONS distributor.
How do I troubleshoot issues or seek technical support for part 57202G5203ALF?
You can download the 57202G5203ALF datasheet or visit the AMPHENOL COMMUNICATIONS SOLUTIONS website for support.
Who is the manufacturer of 57202G5203ALF?
AMPHENOL COMMUNICATIONS SOLUTIONS
