AMPHENOL COMMUNICATIONS SOLUTIONS 76341311LF Dubox Shunts
AMPHENOL's Dubox™ Shunts are robust board-to-board connectors designed for reliable signal transmission. These connectors feature dual-beam contacts, ensuring added reliability, and a slotted cutout in the low-profile housing simplifies electrical testing. Their stackable design allows for efficient use of space in various industrial applications. Constructed with high-temperature thermoplastic housing and phosphor-bronze pins with gold or tin plating, these shunts offer excellent performance and durability.
AMPHENOL COMMUNICATIONS SOLUTIONS 76341311LF Dubox Shunts Specifications:
- Housing: High temperature, black thermoplastic
- Flammability rating: UL94V-0
- Pin: Phosphor-bronze
- Plating: Gold or tin over 1.27μm (50μin.) nickel
- File no.: E66906
- File no. LR46923: LR46923
- Current rating: 2.5A max. per contact
- Insulation resistance: 50,000MΩ min
- Contact resistance: 15MΩ max. initial, 20MΩ max. after environmental tests
- Dielectric withstanding voltage: 800V
- Operating temperature range: -65°C to +125°C
- Mating cycles (durability): 50-Gold, 25-Tin
- Insertion force (gold contact): 450gf max.
- Insertion force (tin-lead contact): 500gf max.
- Withdrawal force (gold contact): 30gf min.
- Withdrawal force (tin-lead contact): 30gf min.
- Insertion depth: 4.85 mm (.191in.) min.
- Packaging: Plastic bags
Buy the 76341-311LF AMPHENOL COMMUNICATIONS SOLUTIONS Dubox Shunts | myMectronic
Securely purchase the 76341-311LF Dubox Shunt online for all your electronic component needs.
Buy Now
Frequently Asked Questions
Where can I buy AMPHENOL COMMUNICATIONS SOLUTIONS 76341311LF?
You can click on the BUY or RFQ button to purchase 76341311LF from an authorized AMPHENOL COMMUNICATIONS SOLUTIONS distributor.
How do I troubleshoot issues or seek technical support for part 76341311LF?
You can download the 76341311LF datasheet or visit the AMPHENOL COMMUNICATIONS SOLUTIONS website for support.
Who is the manufacturer of 76341311LF?
AMPHENOL COMMUNICATIONS SOLUTIONS
