AMPHENOL COMMUNICATIONS SOLUTIONS HM2P95PD8110N9LF 2mm Modular Vertical Connector
The Millipacs 2mm Hard Metric series vertical header connectors are modular, high-performance interconnects designed for board-to-board and cable-to-board applications in communication, data, medical, and industrial sectors. These connectors feature a 2mm pitch, various lengths, and hybrid options with signal, power, and coax contacts, ensuring versatility and scalability for high-speed data transmission up to 10Gbps. Made of UL94V0 thermoplastic insulators with gold, palladium, and tin plating, they meet IEC standards, and operate in temperatures from -55°C to +125°C. Suitable for high-density, modular designs with optional shielding and polarization features.
AMPHENOL COMMUNICATIONS SOLUTIONS HM2P95PD8110N9LF 2mm Modular Vertical Connector Specifications:
- Pitch: 2mm
- Operating temperature: -55°C to +125°C
- Contact material: Copper Alloy
- Contact plating: Gold / Palladium nickel, Tin over Nickel
- Electrical: Operating current 1.5A at 20°C, test voltage 750 Vrms
- Contact resistance: 20 mΩ max
- Insulation resistance: 10 MΩ min
- Mating force: 0.75 N max per contact
- Withdrawal force: 0.15 N min per contact
- Misalignment: Longitudinal + 2.0mm, Transversal + 2.5mm
- Certification: IEC 917, IEC 61076-4-101, UL, CSA, Telcordia GR-1217-CORE
- Packaging: Tray and tape & reel options
- Application: High-speed data, industrial control, medical imaging
Buy the Buy FCI Millipacs 2mm Hard Metric Part Number HM2P95PD8110N9LF Online
Purchase the FCI Millipacs 2mm modular vertical connector online for versatile, high-speed interconnection solutions suitable for communication, data, medical, and industrial applications. Designed for high performance, these connectors support data rates up to 10Gbps, ensuring fast and reliable signal transfer. Made with durable materials, they operate across a temperature range of -55°C to +125°C and meet IEC standards. Easy to install with optional shielding and polarization features, perfect for scalable, dense PCB designs. Buy now for quality and dependable performance.
Order your FCI Millipacs 2mm Hard Metric Part Number HM2P95PD8110N9LF today and ensure your next project benefits from reliable and scalable high-speed interconnects.
Frequently Asked Questions
Where can I buy AMPHENOL COMMUNICATIONS SOLUTIONS HM2P95PD8110N9LF?
You can click on the BUY or RFQ button to purchase HM2P95PD8110N9LF from an authorized AMPHENOL COMMUNICATIONS SOLUTIONS distributor.
How do I troubleshoot issues or seek technical support for part HM2P95PD8110N9LF?
You can download the HM2P95PD8110N9LF datasheet or visit the AMPHENOL COMMUNICATIONS SOLUTIONS website for support.
Who is the manufacturer of HM2P95PD8110N9LF?
AMPHENOL COMMUNICATIONS SOLUTIONS
