AMPHENOL COMMUNICATIONS SOLUTIONS MRUAM214000 USB Type A Connector
The MRUAM21-4000 is a high-performance USB 2.0 Type A connector with a bayonet lock, designed for reliable hardwire connections in industrial and professional applications. It features a rugged construction with a stainless steel shield, gold-plated copper alloy contacts, and RoHS-compliant thermoplastic housing rated UL 94V-0. Suitable for wire gauges up to 24 AWG, it offers ingress protection of IP67/68, operates efficiently between -45°C to +85°C, and supports data transfer speeds up to 480 Mbps. Its durable design ensures over 1500 mating cycles for long-term use.
AMPHENOL COMMUNICATIONS SOLUTIONS MRUAM214000 USB Type A Connector Specifications:
- Number of contacts: 4
- Wire gauge: 24 AWG
- Ingress protection: IP67 / 68
- Mechanical life: 1500 mating cycles
- Operating temperature: -45°C to +85°C
- DWV: 500VAC / 1 minute at sea level
- Speed: 480 Mbps
- Contact resistance: 30 milliohms max
- Insulation resistance: 1000 megaohms min
- Current rating: 1.54A
- Recommended cable outer diameter: 3.5mm (.138") - 66.8mm (.268")
- Housing & components: Glass-filled thermoplastic, stainless steel shield, copper alloy contacts plated with gold over nickel, silicon rubber gaskets
- RoHS compliant materials
Buy the Amphenol Series USB 2.0 Type A Bayonet Lock: MRUAM214000
Discover the reliability of the USB Type A connector with bayonet lock by Amphenol. Designed for industrial and professional settings, it features a durable stainless steel shield, gold-plated contacts, and IP67/68 ingress protection. Operating from -45°C to +85°C, it supports data speeds up to 480 Mbps and withstands over 1500 mating cycles. Ideal for rugged environments requiring stable, high-performance data transfer, this connector ensures long-lasting connections in challenging conditions.
Order your Amphenol Series USB 2.0 Type A Bayonet Lock MRUAM21-4000 today and ensure secure, rugged connections for industrial projects.
Frequently Asked Questions
Where can I buy AMPHENOL COMMUNICATIONS SOLUTIONS MRUAM214000?
You can click on the BUY or RFQ button to purchase MRUAM214000 from an authorized AMPHENOL COMMUNICATIONS SOLUTIONS distributor.
How do I troubleshoot issues or seek technical support for part MRUAM214000?
You can download the MRUAM214000 datasheet or visit the AMPHENOL COMMUNICATIONS SOLUTIONS website for support.
Who is the manufacturer of MRUAM214000?
AMPHENOL COMMUNICATIONS SOLUTIONS
