AMPHENOL COMMUNICATIONS SOLUTIONS MUSB2K15005BP Rugged USB Connector
The MUSB2K15005BP is a rugged USB 2.0 Type A connector designed for harsh environments, providing IP67 sealing, die cast zinc housing, and elevated temperature resistance. It features flexible silicone rubber seals, compact low-profile design, and various mounting options suitable for industrial, automotive, and medical applications, ensuring reliable water and dust protection. Operating between -40°C to +105°C, this connector withstands shock, vibration, and mechanical impacts, making it ideal for outdoor and demanding industrial settings. Certified RoHS compliant, it supports high durability and environmental standards.
AMPHENOL COMMUNICATIONS SOLUTIONS MUSB2K15005BP Rugged USB Connector Specifications:
- External Shell: Die Cast Zinc, Nickel Plated
- Insulator Housing: High Temperature Resistant Engineering Thermoplastic, Glass Reinforced, UL94V-0
- Sealing: IP67 waterproof and dustproof
- Operating Temperature Range: -40°C to +105°C
- Current Rating: 1.54A max per contact
- Contact Resistance: 30mΩ max
- Dielectric Withstanding Voltage: 500VAC rms
- Material: Die cast zinc shell, thermoplastic insulator
- Solderability: Per EIA-364-52, 95% coverage
- Flammability: UL 94V-0
- Certifications: RoHS compliant
- Humid Tests: 240 hours at 25°C, 65% RH
- Salt Spray: 250 hours at 5%, 35°C
- Shock & Vibration: Meets IEC specifications
- Standards: USB 2.0
Buy the Amphenol Series MUSBR USB Connectors: MUSB2K15005BP
Order the Amphenol MUSB2K15005BP rugged USB 2.0 Type A connector online today and ensure reliable, dustproof, and waterproof data transfer in harsh conditions. Its robust die cast zinc housing and IP67 sealing protect electronics from water, dust, shock, and vibration, making it ideal for industrial machinery, outdoor equipment, and medical devices. With wide operating temperature tolerance from -40°C to +105°C, it's suitable for outdoor and demanding applications. Enjoy quick delivery and secure checkout for this high-durability, RoHS-compliant USB connector designed to meet your rigorous technical needs.
Buy Amphenol MUSB2K15005BP rugged USB Type A connector now and experience unmatched durability and high-performance connectivity in extreme environments.
Frequently Asked Questions
Where can I buy AMPHENOL COMMUNICATIONS SOLUTIONS MUSB2K15005BP?
You can click on the BUY or RFQ button to purchase MUSB2K15005BP from an authorized AMPHENOL COMMUNICATIONS SOLUTIONS distributor.
How do I troubleshoot issues or seek technical support for part MUSB2K15005BP?
You can download the MUSB2K15005BP datasheet or visit the AMPHENOL COMMUNICATIONS SOLUTIONS website for support.
Who is the manufacturer of MUSB2K15005BP?
AMPHENOL COMMUNICATIONS SOLUTIONS
