Amphenol-Communications-Solutions L17DTSL37RGLJSTL77SDC37S Solder Cup Connector
The solder cup D-Sub connectors are reliable, top-entry, shielded connectors designed for secure cable connections in electronic systems. Crafted from zinc with nickel plating for durability, they operate effectively within -40°C to +120°C. Featuring glass-filled insulators with UL94 V-0 rating, steel shells, and copper alloy contact pins plated with gold over nickel, these connectors support currents up to 5A and withstand voltages over 1000V RMS. Suitable for sizes 9, 15, 25, and 37, they are ideal for robust, EMI-shielded, quick-assembly connections with long jackscrews for secure fastening.
Amphenol-Communications-Solutions L17DTSL37RGLJSTL77SDC37S Solder Cup Connector Specifications:
- Material: Zinc, Nickel Plated
- Operating Temperature: -40°C to +120°C
- Cable Entry: Top Entry
- Strain relief: Clamp + Insert
- Thumbscrews: Long Jackscrews
- Contact pins: Copper Alloy, Gold Flash over Ni.
- Insulator: Glass filled TP, UL94 V-0
- Shell: Steel, Tin Plated
- Contact Plating: Gold Flash over Nickel
- Withstanding Voltage: >1000V Rms to 50 Hz
- Current Rating: 5A
- Insulator Resistance: >5000MQ min.
- Sizes Available: 9, 15, 25, 37
- Dimensions vary by size, e.g., 9-way: 32.2mm x 42.0mm x 15.0mm
- Suitable for wire O.D.: Up to 11.5mm
Buy the Amphenol Series Solder Cup: L17DTSL37 RGLJSTL77SDC37S
Discover the high-reliability solder cup connectors designed for secure and EMI-shielded cable connections in electronics. Made from zinc with durable nickel plating, these connectors operate within -40°C to +120°C, supporting currents up to 5A and voltages over 1000V RMS. Their glass-filled UL94 V-0 insulator provides thermal safety, while their robust steel shells and gold-plated contacts ensure long-lasting performance. Available in sizes 9, 15, 25, and 37, they feature quick assembly, long jackscrews, and top entry cable routing for versatile applications in industrial and electronic systems.
Order your Amphenol Series Solder Cup L17DTSL37 RGLJSTL77SDC37S today and give your electronic connections the dependable, EMI-shielded quality they deserve.
Frequently Asked Questions
Where can I buy Amphenol-Communications-Solutions L17DTSL37RGLJSTL77SDC37S?
You can click on the BUY or RFQ button to purchase L17DTSL37RGLJSTL77SDC37S from an authorized Amphenol-Communications-Solutions distributor.
How do I troubleshoot issues or seek technical support for part L17DTSL37RGLJSTL77SDC37S?
You can download the L17DTSL37RGLJSTL77SDC37S datasheet or visit the Amphenol-Communications-Solutions website for support.
Who is the manufacturer of L17DTSL37RGLJSTL77SDC37S?
Amphenol-Communications-Solutions
