AMPHENOL LTW MSAS06PMMSSF8C30 Shielded Industrial Connector
This shielded connector features waterproof rating IP68/IP69K, made from durable nylon GF black, with copper alloy gold-plated male pins. It supports a rated voltage of 250V AC/DC across four pins, with current ratings up to 4A. The connector is designed for high environmental resistance, suitable for panel thickness up to 4.5mm, with assembly torque between 4-6 Kgf.cm. It includes zinc alloy shield and screw nuts, Viton panel O-ring, and flexible wire harness options from 150mm to 1500mm, ideal for industrial automation and electronic control systems.
AMPHENOL LTW MSAS06PMMSSF8C30 Shielded Industrial Connector Specifications:
- Waterproof rating: IP68/IP69K
- Material: Nylon GF, Black
- Male Pin Material: Copper Alloy, Gold Plated
- Shield Material: Zinc Alloy, Nickel Plated
- Screw Nut Material: Zinc Alloy, Nickel Plated
- Panel O-Ring: Viton, Black
- Rated Voltage: 250V AC/DC
- Rated Current: 4A (4-pin support)
- Operating Temperature: -25°C to +85°C
- Max Panel Thickness: 4.5mm
- Nut Torque: 4-6 Kgf.cm
- Wire Harness Lengths: 150mm to 1500mm (custom options available)
- Connector Size: M16 x 1.5
- Suitable for panel cut-outs: over 1000mm: 440mm
- Rated Voltage for different pins: 3-8 Pin supports 250V, 6-12 Pin supports 30V, 6-8 Pin supports 30V
- Mounting Type: Front with wire harness
Buy the Allen Pan Series Shielded Waterproof Connector: MSAS06PMMSSF8C30
Purchase the highly reliable shielded industrial connector online today to ensure your equipment maintains optimal performance in harsh environments. This connector offers excellent waterproof rating IP68/IP69K, corrosion-resistant zinc alloy shield, and gold-plated copper pins for superior conductivity. Its versatile wire harness options, supporting lengths from 150mm to 1500mm, make it ideal for automation systems, control panels, and electronic devices. Easily install with recommended torque and panel compatibility, making your setup safer and more efficient.
Order your Allen Pan Series MSAS06PMMSSF8C30 waterproof connector today and secure your industrial automation projects with dependable, high-quality wiring solutions.
Frequently Asked Questions
Where can I buy AMPHENOL LTW MSAS06PMMSSF8C30?
You can click on the BUY or RFQ button to purchase MSAS06PMMSSF8C30 from an authorized AMPHENOL LTW distributor.
How do I troubleshoot issues or seek technical support for part MSAS06PMMSSF8C30?
You can download the MSAS06PMMSSF8C30 datasheet or visit the AMPHENOL LTW website for support.
Who is the manufacturer of MSAS06PMMSSF8C30?
AMPHENOL LTW
