AMPHENOL RF 095850221048 Waterproof RF Connectors
The TNC and RP-TNC waterproof connectors are designed for robust, outdoor, and industrial applications, offering IP67-rated waterproofing and tamper resistance. These connectors feature a threaded coupling for secure connections and are available in straight, right-angle, bulkhead, and PCB mount configurations. Made with durable brass, beryllium copper, and PTFE insulators, they operate from DC to 11 GHz, with excellent VSWR, dielectric withstanding voltage, and insulation resistance. Suitable for antennas, wireless systems, military, and broadband applications, they support up to 500 mating cycles and withstand temperatures from -65°C to +165°C.
AMPHENOL RF 095850221048 Waterproof RF Connectors Specifications:
- Impedance: 50 Ohms
- Frequency Range: DC to 11 GHz
- Return Loss (VSWR): 3 (-18 dB) Max.
- Dielectric Withstanding Voltage: 1500 VRMS Max.
- Insulation Resistance: 5000 MΩ Min.
- Contact Resistance: Center Contact 1.5 mΩ Max., Outer Contact 0.2 mΩ Max.
- Coupling Style: Threaded
- Mating Cycles: 500 Min.
- Temperature Range: -65°C to +165°C
- Materials: Body and Outer Contacts Brass, Male Contact Beryllium Copper, Female Contact Brass, Crimp Ferrule Copper, Insulator PTFE, Gasket Silicone
- RoHS: Yes
Buy the Amphenol RF 095850221- Reliable Waterproof Connectors for Industrial Applications
Secure your communication systems with Amphenol RF waterproof connectors, offering IP67-rated protection, tamper resistance, and durable construction. Designed for antennas, wireless, military, and broadband systems, these connectors feature a threaded interface for secure connections and are available in various configurations including straight, right-angle, and bulkhead mounts. Made with high-quality materials like brass and PTFE insulators, they operate up to 11 GHz, ensuring high performance and long-term reliability. Easy to install and suitable for harsh environments, order now online.
Buy Amphenol RF 095850221 now and experience unmatched reliability and performance for outdoor and industrial connectivity needs.
Frequently Asked Questions
Where can I buy AMPHENOL RF 095850221048?
You can click on the BUY or RFQ button to purchase 095850221048 from an authorized AMPHENOL RF distributor.
How do I troubleshoot issues or seek technical support for part 095850221048?
You can download the 095850221048 datasheet or visit the AMPHENOL RF website for support.
Who is the manufacturer of 095850221048?
AMPHENOL RF
