Amphenol Sine Systems AT0412PDPM12 12 Pin Receptacle with Flange
The Amphenol Sine Systems AT04-12PD-PM12 is a high-performance, 12-pin circular connector designed for demanding industrial environments. It incorporates a thermoplastic housing, end cap, strain relief cap, and silicone rubber seals, providing excellent environmental protection. The connector's robust construction and IP67 rating make it ideal for applications in automotive, heavy equipment, and industrial automation. It supports various wire gauges and offers both gold-plated and nickel-plated contact options for optimal conductivity and corrosion resistance. The AT series connectors are known for their reliability and ease of integration into diverse systems.
Amphenol Sine Systems AT0412PDPM12 12 Pin Receptacle with Flange Specifications:
- Material (Housing): Thermoplastic
- Material (End Cap): Thermoplastic
- Material (Strain Relief Cap): Thermoplastic
- Material (Seals): Silicone Rubber
- Color (Housing): Per Key Option
- Color (End Cap): Black
- Color (Strain Relief Cap): Black
- Color (Seals): Red
- Current Rating: 13 Amps
- Operating Temperature: -55°C to +125°C
- Dielectric Withstanding Voltage: Less than 2 Milliamps
- Insulation Resistance: 1000 Megohms Min @ 25°C
- Moisture Resistance: IP67 (Mated Condition)
- Mating Cycle Durability: 100 Cycles
- RoHS Compliant: Yes
- Contact Size: 16
- Insulation O.D. (Min): 1.35 mm
- Insulation O.D. (Max): 3.05 mm
- Wire Range: 14 - 20 AWG
Buy the AT04-12PD-PM12 Amphenol Sine Systems 12 Pin Receptacle with Flange | myMectronic
Purchase the Amphenol Sine Systems AT04-12PD-PM12 connector securely and reliably online.
Buy Now
Frequently Asked Questions
Where can I buy Amphenol Sine Systems AT0412PDPM12?
You can click on the BUY or RFQ button to purchase AT0412PDPM12 from an authorized Amphenol Sine Systems distributor.
How do I troubleshoot issues or seek technical support for part AT0412PDPM12?
You can download the AT0412PDPM12 datasheet or visit the Amphenol Sine Systems website for support.
Who is the manufacturer of AT0412PDPM12?
Amphenol Sine Systems
