Amphenol Sine Systems ATHP042P25EL Mini Power Connector
The Amphenol Sine Systems ATHP042P25EL is a miniature circular power connector designed for demanding applications. Constructed with a thermoplastic housing, silicone rubber seal, copper alloy power contacts, and nickel-plated shielding, this connector offers excellent durability and protection against environmental factors. It is rated for a current up to 35 amps with 6.0mm² wire size and features a voltage rating of 1000 V AC/DC. The ATHP042P25EL is ideal for automotive, industrial automation, and power distribution systems where compact size and reliable performance are critical.
Amphenol Sine Systems ATHP042P25EL Mini Power Connector Specifications:
- Current Rating: 6.0mm² @ 35 Amps, 4.0mm² @ 25 Amps, 2.5mm² @ 20 Amps
- Voltage Rating: 1000 V AC/DC
- Operating Temperature: -40°C to +130°C
- Dielectric Withstanding Voltage: Less than 2 milliamps @ 3000 Volts AC
- Insulation Resistance: 500 Megohms Min @ 25°C
- Degree of Protection: IP67 (mated condition)
- Mating Cycle Durability: 100 cycles
- Material: {'Housing': 'Thermoplastic UL 94V0', 'Seal': 'Silicone Rubber', 'Power Contact': 'Copper Alloy, Tin Plated', 'Shielding': 'Copper Alloy, Nickel Plated'}
- Contact Types: ['MP10B23T/MS10B23T (12-10 AWG, 3.0-6.0 mm²)', 'SP12A1T/SS12A1T (2.5mm, 2.5-3.5 mm²)', 'SP12A1T-10/SS12A1T-10 (4.0mm, 4mm²)', 'MP10B23S/MS10B23S', 'MP10B23F/MS10B23F', 'MP10B23G5/MS10B23G5', 'MP10B23G10/MS10B23G10', 'MP10B23G15/MS10B23G15', 'MS10B23G30/MS10B23G30']
Buy the ATHP042P25EL Amphenol Sine Systems Mini Power Connector | myMectronic
Purchase the Amphenol Sine Systems ATHP042P25EL securely and efficiently for your industrial needs.
Buy Now
Frequently Asked Questions
Where can I buy Amphenol Sine Systems ATHP042P25EL?
You can click on the BUY or RFQ button to purchase ATHP042P25EL from an authorized Amphenol Sine Systems distributor.
How do I troubleshoot issues or seek technical support for part ATHP042P25EL?
You can download the ATHP042P25EL datasheet or visit the Amphenol Sine Systems website for support.
Who is the manufacturer of ATHP042P25EL?
Amphenol Sine Systems
