Amphenol Sine Systems ATM0408PAKT01 8 Position ATM Receptacle Kit
The Amphenol Sine Systems ATM04-08PA-KT01 is a robust 8-position circular connector kit engineered for use in a wide range of industrial applications. The kit includes a receptacle, multiple contacts, and a wedgelock for secure attachment. Constructed with a thermoplastic housing, silicone rubber seals, and nickel-plated copper alloy contacts, this connector provides excellent environmental protection and reliable performance. It is designed to withstand harsh conditions, including moisture and temperature extremes, making it suitable for automotive, industrial automation, and power transmission applications. The ATM04 series is known for its durability and ease of use, ensuring a secure and long-lasting connection.
Amphenol Sine Systems ATM0408PAKT01 8 Position ATM Receptacle Kit Specifications:
- current_rating: 7.5 Amps
- operating_temperature: -55°C to +125°C
- dielectric_withstanding_voltage: Less than 2 milliamp current leakage @ 1500 Volts AC
- insulation_resistance: 1000 Megohms Min @ 25°C
- contact_millivolt_drop: 60 Millivolt Drop @ 7.5 Amp Test Current
- moisture_resistance: IP67 (mated condition)
- connector_mating_cycle_durability: 100 Cycles
- housing_material: Thermoplastic, Grey
- wedgelock_material: Thermoplastic, Orange
- seal_material: Silicone Rubber
- contact_material: Copper Alloy, Nickel Plated
- wire_range: 20 - 22 AWG
- contact_od: 1.35 mm
- max_insulation_od: 3.05 mm
Buy the ATM04-08PA-KT01 Amphenol Sine Systems 8 Position ATM Receptacle Kit | myMectronic
Purchase the Amphenol Sine Systems ATM04-08PA-KT01 securely and conveniently online.
Buy Now
Frequently Asked Questions
Where can I buy Amphenol Sine Systems ATM0408PAKT01?
You can click on the BUY or RFQ button to purchase ATM0408PAKT01 from an authorized Amphenol Sine Systems distributor.
How do I troubleshoot issues or seek technical support for part ATM0408PAKT01?
You can download the ATM0408PAKT01 datasheet or visit the Amphenol Sine Systems website for support.
Who is the manufacturer of ATM0408PAKT01?
Amphenol Sine Systems
