Amphenol Sine Systems RTS6BS14N19S03 Circular Connector Backshell
The Amphenol Sine Systems RTS6BS14N19S03 is a circular connector backshell engineered for demanding industrial environments. Constructed from thermoplastic material with a UL94 V-0 rating, it offers excellent flame retardancy and durability. The backshell is designed to provide a secure and reliable connection for circular connectors, ensuring optimal performance and longevity in applications such as industrial automation, transportation, and power distribution. Its robust design and RoHS compliance make it a suitable choice for a wide range of applications requiring high-performance connectivity.
Amphenol Sine Systems RTS6BS14N19S03 Circular Connector Backshell Specifications:
- Material: Shell: Thermoplastic, UL94 V-0; Insert: Thermoplastic, UL94 V-0; Coupling Nut: Thermoplastic, UL94 V-0; O-Ring: NBR or Silicone Rubber; Washer: Silicone Rubber; Back Shell: Thermoplastic, UL94 V-0; Clamp Nut: Thermoplastic, UL94 V-0; Clamp Ring: Thermoplastic, UL94 V-0; Cable Seal: EPDM
- Rated Current: 5A (MAX)
- Rated Voltage: 250V (AC/DC)
- Operating Temperature: -40°C ~ +105°C
- Dielectric Withstanding Voltage: Less than 2 Milliamps Current Leakage @ 2000 Volts AC
- Insulation Resistance: 5000 Megohms Min
- IP Class: IP67 and IP69K in the mated condition
- Mating Cycles Durability: 500 Cycles Min
- RoHS Compliant: Yes
- Cable OD Range: 9.0-14.0MM
- Contact Size: 20
- Suitable Contacts: 20# Contact
