Amphenol Sine Systems ATM0412PAPM01 Keyed 12 Pin Receptacle
The Amphenol Sine Systems ATM04-12PA-PM01 is a robust, keyed circular connector designed for demanding industrial applications. Its keyed design ensures proper mating, while the thermoplastic housing and silicone rubber seal provide environmental protection. The connector is RoHS compliant and rated to IP67, making it suitable for use in harsh environments. It is commonly used in automotive, industrial automation, and power transmission systems where a reliable and secure connection is critical. The ATM series offers a wide range of contact options and tooling to meet diverse application requirements.
Amphenol Sine Systems ATM0412PAPM01 Keyed 12 Pin Receptacle Specifications:
- Current Rating: 7.5 Amps
- Operating Temperature: -55°C to +125°C
- Dielectric Withstanding Voltage: Less than 2 milliamps current leakage @ 1500 Volts AC
- Insulation Resistance: 1000 Megohms Min @ 25°C
- Moisture Resistance: IP67 (mated condition)
- Mating Cycle Durability: 100 cycles
- Material (Housing): Thermoplastic
- Material (Seal): Silicone Rubber
- Keyway: 3 places
Buy the ATM04-12PA-PM01 Amphenol Sine Systems Keyed 12 Pin Receptacle | myMectronic
Purchase the Amphenol Sine Systems ATM04-12PA-PM01 securely and reliably through our online store.
Buy Now
Frequently Asked Questions
Where can I buy Amphenol Sine Systems ATM0412PAPM01?
You can click on the BUY or RFQ button to purchase ATM0412PAPM01 from an authorized Amphenol Sine Systems distributor.
How do I troubleshoot issues or seek technical support for part ATM0412PAPM01?
You can download the ATM0412PAPM01 datasheet or visit the Amphenol Sine Systems website for support.
Who is the manufacturer of ATM0412PAPM01?
Amphenol Sine Systems
