Anderson Power Products 1381G3BK Powerpole Connector
Powerpole connectors are cost-effective and reliable electrical connectors suitable for industrial and electronic applications. Designed for high current capacity, they accommodate wire sizes up to 3/0 AWG and feature silver-plated contacts for superior conductivity and durability. The connectors are stackable, color-coded for easy identification, and UL rated for hot plugging up to 75 amps, making them ideal for quick disconnect systems, battery, and power distribution. Options include wire contacts, busbar contacts, mounting clamps, and retaining pins for versatile installation in various electrical systems.
Anderson Power Products 1381G3BK Powerpole Connector Specifications:
- Current Rating: 350 Amps for wire-wire connections, 180 Amps for wire-busbar
- Wire Size Range: 10 to 3/0 AWG (5.3 to 85 mm²)
- Voltage Rating: 600 V AC/DC
- Operating Temperature: -4°F to 221°F (-20°C to 105°C)
- Material: Copper alloy contact with silver plating
- Dielectric Withstanding Voltage: 2,200 Volts AC
- Mating Cycles: 10,000 for contacts, 250 for wire-to-wire
- Housing Material: Polycarbonate (UL94 V0)
- Protection Class: IEC 60529 IP10
- Contact Resistance: 0.100 Milliohms (for 6 inches of 1/0 AWG wire)
- UL Hot Plug Current Rating: 120 Amps
Buy the Anderson Powerpole® 1381G3BK – Reliable Power Distribution for Industrial Applications
Enhance your electrical setup with Powerpole connectors, offering high current capacity, reliable performance, and quick disconnect features. Ideal for manufacturing, installation, and maintenance of industrial electrical systems, these stackable, color-coded connectors ensure safety and ease of identification. With silver-plated contacts rated up to 350 amps and UL certified for hot plugging, they provide durability and efficient power distribution. Available with wire and busbar contacts, mounting clamps, and retaining pins for flexible installation. Buy online today and ensure secure, reliable electrical connections for your projects.
Get Anderson Powerpole® 1381G3BK today—built for versatile power distribution and long-lasting durability in industrial and electronic systems.
Frequently Asked Questions
Where can I buy Anderson Power Products 1381G3BK?
You can click on the BUY or RFQ button to purchase 1381G3BK from an authorized Anderson Power Products distributor.
How do I troubleshoot issues or seek technical support for part 1381G3BK?
You can download the 1381G3BK datasheet or visit the Anderson Power Products website for support.
Who is the manufacturer of 1381G3BK?
Anderson Power Products
