Anderson Power Products 269G2LPBK rotational connector
The Anderson Power Products Multi-Axial Rotational Connector features eight Powerpole circuits in a durable, chemically resistant PBT housing. Designed for blindmating from two rotating axes or straight, it uses flat wiping contacts rated up to 29 amps per circuit. Configurable with eight or six contacts plus two pre-mate multi-purpose contacts serving as ground, power, or signal. It is UL listed, rated for up to 10,000 mating cycles, making it suitable for high-reliability industrial applications requiring robust electrical and mechanical performance.
Anderson Power Products 269G2LPBK rotational connector Specifications:
- Electrical Current Rating: 29A per circuit at 30°C rise
- Voltage Rating: 600V AC/DC per UL1977, 150V DC per EN1175-1
- Contact Material: Tin or silver plated for ground or power contacts
- Temperature Range: -40°C to +125°C
- Mechanical: Up to 10,000 mating cycles, contact retention force 25 lbf
- Maximum Wire Insulation Diameter: 0.175 inches (4.45 mm)
- Housing Material: PBT plastic, flammability UL94 V-0
- Wire Sizes Compatible: #10 to #20 AWG (2.6 mm² to 0.52 mm²)
- Connectors are interchangeably genderless for quick assembly
- Rated for 45A premate ground wire contacts, rated up to 10,000 mating cycles with silver contacts
- Connector height and width fit standard industrial panel cut-outs, with rugged construction for harsh environments
- Includes accessories like float and fixed mount kits for versatile installation
- Approvals: UL listed, RoHS compliant
Buy the Anderson Power Products 269G2LPBK – Reliable Rotational Connector for Industrial Applications
Experience superior performance with the Anderson Power Products rotational connector, designed for demanding industrial uses. With up to 10,000 mating cycles and rated for 29 amps per circuit, this connector ensures long-lasting and reliable electrical connections. Constructed from chemically resistant PBT plastic, it withstands harsh environments while maintaining excellent electrical conductivity. Its interchangeable, genderless design simplifies assembly, reducing downtime and inventory. Perfect for automation, machinery, and high-reliability power systems, purchase online today for fast delivery and exceptional quality assurance.
Get Anderson Power Products 269G2LPBK today—built for industrial automation and high-cycle reliability.
Frequently Asked Questions
Where can I buy Anderson Power Products 269G2LPBK?
You can click on the BUY or RFQ button to purchase 269G2LPBK from an authorized Anderson Power Products distributor.
How do I troubleshoot issues or seek technical support for part 269G2LPBK?
You can download the 269G2LPBK datasheet or visit the Anderson Power Products website for support.
Who is the manufacturer of 269G2LPBK?
Anderson Power Products
