Apem A0154BD Emergency Stop Switch
The emergency stop switch assembly features a robust design suitable for panel mounting with IP65 sealing for front panels and IP40 for the rear. It includes a choice of actuators such as mushroom head, finger grip, or smooth variants, with a double pole normally closed switch block. Engineered for safety and reliability, it operates within -20°C to +55°C, with a mechanical life of 6050 cycles. Compliant with EN 60947-5-5, it offers quick installation, sealed contact mechanism, and maximum panel thickness of 6mm. Suitable for industrial safety applications requiring rapid emergency shutdown controls.
Apem A0154BD Emergency Stop Switch Specifications:
- Electrical function: push to shut off, twist to release
- Current/voltage rating: AC-15 1.5A 250VAC, 6A 250VAC
- Electrical life: 6,050 cycles
- Contact gap: >3mm
- Insulation resistance: Min
- Dielectric test voltage: 2900V
- Panel thickness: Max 6mm (.236)
- Mechanical life: 6050 cycles
- Operating force: 18 to 20N
- Operating temperature: -20°C to +55°C
- Soldering temperature: 350°C, 5 seconds
- Switch terminals: Solder/ Faston 2.8mm (.110)
- Switch block approval: UL1054 / VDE / EN61058-1
- Torque: 0.8Nm
- Sealing: front panel IP65, rear panel IP40
- Material: Operator Case Polyetherimide, Actuator Polycarbonate, Switch block PBT, Panel Seal Neoprene
Buy the Apem Series Emergency Stop: A0154BD
Enhance your safety system with the reliable and durable emergency stop switch. Designed for industrial environments, it features IP65 sealing, various actuator options, and a double pole switch mechanism for fail-safe operation. Easy to install with panel thickness up to 6mm, supporting quick response during emergencies. Operating from -20°C to +55°C, with a mechanical life of over 6000 cycles, ensuring long-term dependable performance in critical safety operations. Perfect for manufacturing, automation, and safety panels requiring rapid shutdown controls.
Buy Apem A0154BD emergency stop switch now and experience unmatched reliability and performance for industrial safety applications.
Frequently Asked Questions
Where can I buy Apem A0154BD?
You can click on the BUY or RFQ button to purchase A0154BD from an authorized Apem distributor.
How do I troubleshoot issues or seek technical support for part A0154BD?
You can download the A0154BD datasheet or visit the Apem website for support.
Who is the manufacturer of A0154BD?
Apem
