Apem Q22F1AGXXSG220E Panel Mount LED Indicator
The Q22F1AGXXSG220E is a 22mm panel mount LED indicator featuring a bright chrome bezel, multiple illumination options, and compatible with various voltages including 220VAC. It includes a color-changing tri-color LED with red, green, and yellow options for versatile signaling. Designed for durability, it offers sealed IP67 housing and is suitable for industrial applications requiring clear visibility and reliable long-term operation. The indicator comes with epoxy sealed wire terminals, customizable engraving options, and is compliant with safety standards for professional automation and control systems.
Apem Q22F1AGXXSG220E Panel Mount LED Indicator Specifications:
- Diameter: 22mm
- Bezel finish: Bright chrome
- Bezel type: Prominent and recessed styles
- Lighting options: Tri-color LED (Red, Green, Yellow)
- Voltage: 220VAC, 207 to 253VAC, 3mA
- Operating voltage range: 207V to 253V
- Operating temperature: -40 to +85°C
- Luminous intensity: Red 465mcd, Green 245mcd, Yellow 365mcd
- Forward voltage: Red 5.7V, Green 9.0V, Yellow 6.0V
- Housing: Sealed IP67 for rugged environments
- Terminals: Epoxy sealed wire, solder lug/fastons
- Life expectancy: 100,000 hours
- Termination length: 200mm UL1007 wire, red (anode), black (cathode)
Buy the APEM Series Q22 LED Indicator: Q22F1AGXXSG220E
Order the Panel Mount LED Indicator designed for industrial applications, featuring a durable sealed IP67 housing and bright tri-color LEDs. Perfect for control panels, this indicator provides clear visual signaling with a 22mm diameter and customizable engraving options. Its rugged construction ensures long-lasting operation up to 100,000 hours, and compatibility with 220VAC power makes it suitable for demanding environments. Enhance your control system with this reliable, easy-to-install LED indicator, available for purchase online today.
Get APEM Q22F1AGXXSG220E today—built for industrial control panels with sealed, tri-color LED signaling.
Frequently Asked Questions
Where can I buy Apem Q22F1AGXXSG220E?
You can click on the BUY or RFQ button to purchase Q22F1AGXXSG220E from an authorized Apem distributor.
How do I troubleshoot issues or seek technical support for part Q22F1AGXXSG220E?
You can download the Q22F1AGXXSG220E datasheet or visit the Apem website for support.
Who is the manufacturer of Q22F1AGXXSG220E?
Apem
