Apem Q22F1AYXXSY24AE Panel-Mount LED Indicator
The Q22F1AYXXSY24AE is a 22mm panel-mounted LED indicator featuring a bright chrome bezel and a diffused epoxy lens. It operates at 24VDC with a forward voltage of 3.3V, producing a luminous intensity of 465mcd in red. Designed for reliable operation, it offers multiple mounting styles, including prominent, recessed, and flush, along with optional IP67 sealing for harsh environments. The LED indicator features solder lug or faston terminals, with an ability to customize engraving and bezel finish, making it suitable for industrial automation, control panels, and premium display applications.
Apem Q22F1AYXXSY24AE Panel-Mount LED Indicator Specifications:
- Diameter: 22mm
- Lens: Diffused epoxy
- Color: Red
- Luminous Intensity: 465mcd
- Forward Voltage: 5.7V
- Operating Voltage: 3.3V at 40mA
- Operating Current: 40mA
- Voltage Range: 3.3 to 99VDC, 220VAC 207 to 253VAC
- Temperature Range: -40°C to +85°C
- Sealing: IP67 option available
- Terminals: Solder lug, faston, or wire
- Bezel Finish: Bright chrome, black chrome, satin grey, or stainless steel
- Mounting: Panel mount
- Durability: 100,000 hours lifetime
- Compliance: UL Recognized Component
Buy the Buy APEM Q22F1AYXXSY24AE Part Number Q22F1AYXXSY24AE Online
Enhance your industrial control panels with the APEM Q22F1AYXXSY24AE LED indicator. Featuring a durable chrome bezel, diffused epoxy lens, and operating at 24VDC, this indicator provides vibrant red illumination with 465mcd intensity. Its IP67 sealing ensures protection against dust and water, suitable for demanding environments. Easy to install with solder lug, faston, or wire terminations, it offers a long lifespan of 100,000 hours. Perfect for automation, machinery, and display applications requiring high visibility and reliability. Order online now!
Order your APEM SeriesQ22F1AYXXSY24AE LED indicator today and enhance your control panels with reliable, high-quality illumination for harsh environments.
