Apem Q6F3CXXB24E LED Indicator
The Q6F3CXXB24E is a blue panel-mount LED indicator with a flush-style bright chrome bezel and wire terminals designed for industrial and signaling applications. It features a 6mm diffused epoxy lens with super bright LEDs, providing highly visible illumination with a life expectancy of 100,000 hours. The indicator supports operating voltages from 2VDC to 28VDC, with a standard operating current of 20mA. It includes fixing components like a nut and spring washer, and offers IP67 sealing protection for durability and moisture resistance.
Apem Q6F3CXXB24E LED Indicator Specifications:
- Lens Diameter: 6mm
- Bezel Finish: Bright chrome
- Mounting Style: Panel mount
- Sealing: IP67 (P67 sealing option)
- Operation Voltage: 2VDC to 28VDC
- Operating Current: 20mA
- Forward Voltage: 3.7V at typical operation
- Luminous Intensity: 550mcd (super bright blue)
- Viewing Angle: 100°
- Life Expectancy: 100,000 hours
- Operating Temperature: -40°C to +85°C
- Inclusion: Fixing nut and spring washer
- Terminals: Wire (200mm length) or Fastons/Solder lug options
- Max Panel Thickness: 7mm
- Reverse Voltage: Max 5V
- Ingress Protection: IP67
- Packaging: Includes fixing components
- Certifications: UL Recognized
Buy the APEM Series Q6 LED Indicator: Q6F3CXXB24E
Order the APEM Series Q6F3CXXB24E blue LED indicator online today and enjoy high visibility and long-lasting operation. Perfect for industrial control panels, signaling, and machinery. Its waterproof IP67 design ensures durability in harsh environments, while the 6mm size makes installation easy. This LED provides brilliant blue illumination with a lifespan of 100,000 hours, operating across a wide voltage range from 2VDC to 28VDC. Fixed with a nut and spring washer, it guarantees secure mountings and reliable performance in demanding applications.
Buy APEM Series Q6F3CXXB24E now and experience unmatched reliability and performance with durable IP67 sealing and bright illumination.
Frequently Asked Questions
Where can I buy Apem Q6F3CXXB24E?
You can click on the BUY or RFQ button to purchase Q6F3CXXB24E from an authorized Apem distributor.
How do I troubleshoot issues or seek technical support for part Q6F3CXXB24E?
You can download the Q6F3CXXB24E datasheet or visit the Apem website for support.
Who is the manufacturer of Q6F3CXXB24E?
Apem
