Apem Q6P5BYYRG24E LED Indicator
The Q6 series panel mount LED indicators are compact, 6 mm diameter devices with various bezel styles, terminal types, and illumination colors including super bright and hyper bright options. They feature epoxy or plastic bodies with IP67 sealing, operating temperature ranges from -40°C to +85°C, and a life expectancy of 100,000 hours. Designed for reliable use in demanding environments, these LEDs provide excellent visibility at wide viewing angles, with stable performance over time thanks to high-quality materials and sealed construction.
Apem Q6P5BYYRG24E LED Indicator Specifications:
- Diameter: 6 mm
- Bezel styles: Prominent, Recessed, Flush
- Materials: Plated brass bezel, molded polycarbonate rear body
- Sealing: IP67 option available
- Operating Temperature Range: -40°C to +85°C
- Storage Temperature Range: -30°C to +65°C (plastic), -40°C to +85°C (epoxy)
- Reverse Voltage Max: 5 V
- View Angle: 30-100°
- Life Expectancy: 100,000 hours
- Electrical: Forward voltage varies by color, operating voltage 1.8-33 VDC, operating current max 20 mA
- LED Colors: Red, Green, Yellow, Blue, White, Orange, bi-color options
- Luminous Intensity: Ranges from 2,000 to 10,000 mcd depending on brightness and color
- Terminal types: Solder lug, rear epoxy pins, short body wires, Faston/Wires
- Max Panel Thickness: 7 mm
Buy the Amphenol Series Q6 LED: Q6P5BYYRG24E
Purchase your Amphenol Q6 LED indicator online today and enjoy quick delivery of high-quality, durable panel mount lights. These compact LEDs come in multiple bezel styles and brightness levels, including super bright and hyper bright options, making them ideal for extensive industrial, automation, and control applications. Their IP67 sealing ensures reliable operation even in harsh environments. Compatible with various voltages, with flexible terminals including solder lug, pins, and wire connections, ensuring easy installation and long-lasting performance.
Order your Amphenol Series Q6 LED indicator today and enhance your projects with durable, high-performance lighting solutions designed for demanding environments.
