BROADCOM HLMPC323 High-Brightness LED Lamp
The HLMP-C323 is a high-brightness LED lamp designed for versatile lighting applications including backlighting, front panel illumination, and signs. It features a 5mm package with a durable design for indoor and outdoor use, offering high luminous efficiency, uniform light distribution, and multiple color options such as red, yellow, orange, green, and emerald green. Its compact size, excellent electrical performance, and robust construction make it ideal for various digital displays, indicator lights, and illumination projects requiring reliable and vibrant color output.
BROADCOM HLMPC323 High-Brightness LED Lamp Specifications:
- Package: T-1 3/4 (5 mm)
- Dimensions: Length 5.00±0.20 mm, Width 8.71 mm, Height 1.85 mm
- Lead Length: 20 mm standard
- Color Options: AlGaAs Red, High Efficiency Red, Yellow, Orange, Green, Emerald Green
- Forward Voltage: typical 1.9V–2.2V at 20mA
- Maximum DC Forward Current: 30mA
- Peak Forward Current (10 sec pulse): 500mA
- Reverse Voltage: 5V
- Junction Temperature: 110°C
- Operating Temperature Range: -20 to +100°C
- Storage Temperature: -40 to +100°C
- Viewing Angle: 15° and 25° options available
- Luminous Intensity: up to 17,000 mcd depending on color and bin
- Wavelength Range: approx. 560 nm to 645 nm depending on color
- Compliance: RoHS
- Maximum Soldering Temperature: 250°C for up to 3 seconds
Buy the Avago Series T-1 3/4 Red LED Lamp: HLMP-C323
Purchase the high-performance HLMP-C323 LED lamp online today to enhance your lighting and indicator needs. Whether for backlighting, signage, or front panel illumination, this compact 5mm LED offers high brightness, uniform light distribution, and excellent electrical characteristics. Designed for indoor and outdoor applications, it ensures reliable operation with a broad color selection including red, yellow, orange, green, and emerald green. Easy to integrate, it provides consistent visibility and long-term durability, making it ideal for various industrial, commercial, and electronic projects.
Order your Avago Series T-1 3/4 HLMP-C323 high-brightness LED today and give your projects the dependable light they deserve with vibrant colors and efficient performance.
Frequently Asked Questions
Where can I buy BROADCOM HLMPC323?
You can click on the BUY or RFQ button to purchase HLMPC323 from an authorized BROADCOM distributor.
How do I troubleshoot issues or seek technical support for part HLMPC323?
You can download the HLMPC323 datasheet or visit the BROADCOM website for support.
Who is the manufacturer of HLMPC323?
BROADCOM
