BROADCOM HSMZA100R00J1 Surface Mount LED Indicator
The HSMZ-A100-R00J1 is a high-reliability PLCC-2 surface-mount red LED indicator made of TS-AlInGaP material. Designed for harsh environments, it offers a wide viewing angle of 120°, a flat top surface for easy light pipe mating, and a built-in reflector to enhance brightness. Compatibility with IR and wave soldering processes ensures manufacturing flexibility. This LED is ideal for interior automotive displays, signage, backlighting in office and industrial equipment, and electronic sign pixels. Its rugged construction and high brightness performance make it suitable for demanding applications.
BROADCOM HSMZA100R00J1 Surface Mount LED Indicator Specifications:
- Package Type: PLCC-2 surface mount
- Material: TS-AlInGaP
- Color: Red
- Viewing Angle: 120°
- Light Emitting Surface: Flat top
- Compatibility: IR solder reflow, wave soldering
- Max Forward Current: 30mA
- Peak Forward Current: 100mA
- Forward Voltage: Typ. 2.2V, Max. 2.6V at 20mA
- Reverse Voltage: 5V
- Junction Temperature: 110°C
- Operating Temperature: -55°C to +100°C
- Storage Temperature: -55°C to +100°C
- Reliability: Suitable for automotive and industrial environments
- Brightness: High, with built-in reflector
- Application: Automotive interior, signage, general backlighting, LED pixels
Buy the Broadcom HSMZ-A100-R00J1 – Reliable LED Indicator for Industrial Applications
Purchase the Broadcom HSMZ-A100-R00J1 LED indicator online today to ensure high reliability and bright illumination in your automotive, signage, or industrial projects. This rugged PLCC-2 surface-mount LED features a 120° viewing angle, flat top for easy alignment with light pipes, and a built-in reflector for enhanced brightness. Compatible with both IR reflow and wave soldering, it provides outstanding performance under harsh conditions. Get this versatile LED now to improve visibility and durability in your electronic devices and signage applications.
Order your Broadcom HSMZ-A100-R00J1 today and get a high-brightness, rugged LED indicator perfect for automotive and industrial lighting solutions.
Frequently Asked Questions
Where can I buy BROADCOM HSMZA100R00J1?
You can click on the BUY or RFQ button to purchase HSMZA100R00J1 from an authorized BROADCOM distributor.
How do I troubleshoot issues or seek technical support for part HSMZA100R00J1?
You can download the HSMZA100R00J1 datasheet or visit the BROADCOM website for support.
Who is the manufacturer of HSMZA100R00J1?
BROADCOM
