BELDEN 74004E01305 Industrial Ethernet Cable
The DataTuff Industrial Ethernet Cat 7 Permanent Installation Cable is designed for robust indoor networking, supporting 10 Gb/s data transfer with solid AWG 23 conductors. It features foil and braid shielding for superior noise resistance, a PVC jacket with UV stabilisation and oil resistance, and is compliant with ISO/IEC 11801 Ed. 2.2 and EN 50173-1 standards. Suitable for indoor environments, it offers excellent electrical, mechanical, and environmental performance, ensuring reliable high-speed data communication in industrial settings.
BELDEN 74004E01305 Industrial Ethernet Cable Specifications:
- Cat 7 Ethernet cable with 4 pairs, 10 Gb/s data transfer speed
- Conductor Material: Solid AWG 23 Copper
- Shielding: Foil and braid with aluminum/polyester tape and tin-plated copper braid
- Outer Jacket: PVC, UV stabilised and oil resistant, 8mm diameter, 0.3mm thickness
- Inner Shield: Aluminum/polyester tape, Outer Shield: Tinned copper braid 65%
- Impedance: 100 Ohm ±15 Ohm, Capacitance Unbalance Max. 30 pF/m
- Max Delay Skew: 40 ns, Max Transfer Impedance: 5 mOhm/m at 1 MHz
- Operational Temperature Range: -40°C to +80°C, Installation: -18°C to +60°C
- Mechanical Strength: Min Elongation at Break Conductors 10%, Jacket tensile strength 12 MPa
- Certifications: ISO/IEC 11801, EN 50173-1, IEC 60332-1-2, EUROPEAN CPR Eca
Buy the Buy Belden Ethernet Cat 7 Part Number 74004E Online
Purchase the Belden Industrial Ethernet Cable online to ensure reliable, high-speed data transmission in demanding industrial environments. Featuring robust shielding, UV-resistant PVC jacket, and compliance with international standards like ISO/IEC 11801 and EN 50173-1, this cable guarantees excellent noise immunity and lasting durability. Its design supports 10 Gb/s speeds, making it ideal for automation, control systems, and high-performance network infrastructures. Buy now for seamless installation and long-term operational efficiency in your industrial setup.
Get Belden 74004E today—engineered for high-speed industrial networking and durable performance.
