BELDEN 8241 Coaxial Cable
The 8241 coaxial cable features a 0.023-inch (23 AWG) solid bare copper or copper-covered steel conductor, insulated with polyethylene. It has a bare copper braid shield with 95% coverage and a black PVC outer jacket, suitable for transmitting electrical signals in various devices. Designed to meet standards such as UL1685, it offers a characteristic impedance of 75 ohms, a velocity of propagation at 66%, and a conductor resistance of 49 Ω/1000 ft. With UL and EU compliance, it is ideal for indoor applications and industrial settings, providing reliable, high-quality signal transmission.
BELDEN 8241 Coaxial Cable Specifications:
- Conductor: 23 AWG solid bare copper or copper-covered steel
- Insulation Material: Polyethylene
- Outer Shield Material: Bare copper braid, 95% coverage
- Outer Jacket Material: PVC, black
- Overall Diameter: 0.240 inches
- Operating Temperature Range: 40°C to +75°C
- UL Temperature Rating: 75°C
- Conductor Resistance: 49 Ω/1000 ft
- Shield Resistance: 2.6 Ω/1000 ft
- Nominal Characteristic Impedance: 75 ohms
- Velocity of Propagation: 66%
- Maximum Voltage: 300 V RMS
- Flame Test: UL1685
- Bulk Reel Lengths Available: 1,000 ft and 7,000 ft
- Applicable Standards & Compliance: UL, EU RoHS, CE, ELV, WEEE, Prop 65
Buy the Buy BELDEN Coaxial Cable Part Number 8241 Online
Order the BELDEN 8241 coaxial cable online today to ensure dependable performance in your signal transmission needs. Crafted with a 23 AWG copper conductor, polyethylene insulation, and a copper braid shield, this cable guarantees high-quality, interference-resistant operation. Suitable for indoor and industrial environments, it complies with UL1685 flame standards and EU RoHS certifications. Available in both 1,000 ft and 7,000 ft reels, it provides excellent value and long-lasting durability, making it the perfect choice for professional installation and high-performance applications.
Get BELDEN 8241 coaxial cable today—built for reliable signal transmission with high-quality copper conductors and durable insulation, ideal for industrial use.
Frequently Asked Questions
Where can I buy BELDEN 8241?
You can click on the BUY or RFQ button to purchase 8241 from an authorized BELDEN distributor.
How do I troubleshoot issues or seek technical support for part 8241?
You can download the 8241 datasheet or visit the BELDEN website for support.
Who is the manufacturer of 8241?
BELDEN
