BELDEN 8281ORG1000 Precision Video Coax Cable
The BELDEN 8281-ORG-1000 Precision Video Coax Cable is a high-performance cable designed for reliable analog video transmission. Constructed with a 20 AWG solid bare copper conductor, polyethylene insulation, and a tinned copper/bare copper double braid shield (95% coverage), this cable minimizes signal loss and interference. Its robust construction and polyethylene jacket make it suitable for a variety of applications, including CCTV systems, video surveillance, and broadcast equipment. The cable is RoHS compliant and offers excellent performance characteristics for demanding video signal transmission needs.
BELDEN 8281ORG1000 Precision Video Coax Cable Specifications:
- Suitable Applications: Analog Video
- Conductor AWG: 20
- Conductor Material: BC - Bare Copper
- Conductor Diameter: 0.031 in
- Conductor Count: 1
- Insulation Material: PE - Polyethylene
- Insulation Diameter: 0.198 in
- Outer Shield Material (Layer 1): Tin ned Copper (TC)
- Outer Shield Coverage (Layer 1): 95%
- Outer Shield Material (Layer 2): Tin ned Copper (TC)
- Outer Shield Coverage (Layer 2): 95%
- Jacket Material: PE - Polyethylene
- Jacket Diameter: 0.305 in
- Conductor DCR: 9.9 Ohm/1000ft
- Outer Shield DCR: 1.1 Ohm/1000ft
- Capacitance: 21 pF/ft
- Inductance: 0.131 µH/ft
- Impedance: Nominal
- Return Loss (RL) @ 5-216 MHz: 27 dB
- Return Loss (RL) @ 216-850 MHz: 23 dB
- Insertion Loss @ 1 MHz: 0.3 dB/100ft
- Insertion Loss @ 3.6 MHz: 0.5 dB/100ft
- Insertion Loss @ 10 MHz: 0.8 dB/100ft
- Insertion Loss @ 71.5 MHz: 2.1 dB/100ft
- Insertion Loss @ 135 MHz: 3 dB/100ft
- Insertion Loss @ 270 MHz: 4.3 dB/100ft
- Insertion Loss @ 360 MHz: 5.1 dB/100ft
- Insertion Loss @ 540 MHz: 6.3 dB/100ft
- Insertion Loss @ 720 MHz: 7.4 dB/100ft
- Insertion Loss @ 750 MHz: 7.6 dB/100ft
- Insertion Loss @ 1000 MHz: 9.2 dB/100ft
- Nominal Delay: 1.54 ns/ft
- Nominal Velocity of Propagation (VP): 66%
- Non-UL Voltage Rating: 2900 V RMS
- Non-UL Temp Rating: 80°C
- Operating Temp Range: -55°C To +80°C
- Bulk Cable Weight: 69 lbs/1000ft
- Max Pull Tension: 168 lbs
- Min Bend Radius: 3 in
- RG Type: 59/U Type
- Suitability - Aerial: Yes - Black only, when supported by messenger wire
- Suitability - Burial: No
- Suitability - Indoor: Yes
- Suitability - Outdoor: Yes - Black only
- Plenum Rating: No
- EU RoHS Compliance Date: 2004-01-01
