BELDEN 8622060500 Multiconductor Cable
The 8622 060500 is a 152.4-meter, 12-core, chrome-colored, unshielded multiconductor cable designed for audio control and instrumentation applications. It features stranded tinned copper conductors, PVC insulation, and a PVC jacket. The cable has a maximum recommended pulling tension of 1619.145 N and operates within a temperature range of -20°C to 80°C. Suitable for industrial and audio use, it adheres to multiple standards including RoHS, WEEE, and UL certifications, making it ideal for professional wiring and control systems in industrial environments.
BELDEN 8622060500 Multiconductor Cable Specifications:
- Stranded tinned copper conductors (19x29)
- Overall diameter: 0.627 in.
- Conductor AWG: 16 AWG
- Insulation Material: PVC
- Outer Jacket Material: PVC
- Maximum Operating Temperature: 80°C
- Minimum Operating Temperature: -20°C
- Maximum Pulling Tension: 364 lbs (1619.145 N)
- Weight: 235 lbs per 1000 ft.
- Applicable Standards: RoHS II, CE, ELV, WEEE, BFR, CA Prop 65
- Certifications: UL Listed, CSA Certified
- Overall length options: 100 ft, 2000 ft, 500 ft with varying weights and color codes
Buy the Buy BELDEN 8622 Series Cable Part Number 8622060500 Online
Secure your audio, control, and instrumentation wiring with the BELDEN Multiconductor Cable. Featuring 12 cores of stranded tinned copper, PVC insulation, and a PVC jacket, it provides excellent durability and performance. Operating from -20°C to 80°C, it is ideal for industrial environments requiring reliable signal transmission. Available in various lengths including 100 ft, 2000 ft, and 500 ft spools, this UL-listed and RoHS-compliant cable guarantees compliance and safety. Order online today for fast delivery and guaranteed quality for your control systems.
Order your BELDEN Series8622 060500 unshielded multiconductor cable today and ensure reliable performance for your audio and instrumentation projects.
Frequently Asked Questions
Where can I buy BELDEN 8622060500?
You can click on the BUY or RFQ button to purchase 8622060500 from an authorized BELDEN distributor.
How do I troubleshoot issues or seek technical support for part 8622060500?
You can download the 8622060500 datasheet or visit the BELDEN website for support.
Who is the manufacturer of 8622060500?
BELDEN
