Belden C7GBSYKC50 Armored PVC Control Cable
The C7GBSYKC50 is a highly durable armored PVC control cable with galvanized steel wire braid shield designed for industrial control applications. It features a PVC insulation and outer sheath, with optional protective ground conductors, suitable for fixed and occasional flexing installations. Ideal for control panels, machinery, and automation systems, this cable complies with DIN VDE 0295, IEC 60228 standards, offering excellent chemical, UV, and mechanical protection. It supports voltage ratings up to 750 V, operating comfortably within -40°C to +80°C, ensuring reliable performance in demanding environments.
Belden C7GBSYKC50 Armored PVC Control Cable Specifications:
- Construction: PVC insulation and jacket, galvanized steel wire braid shield
- Voltage Rating: Up to 1.5 mm²: 300/500 V, from 2.5 mm²: 450/750 V
- Temperature Range: -40°C to +80°C (fixed), -5°C to +70°C (occasional flexing)
- Color Coding: Up to 5 cores: color-coded, above 6 cores: Belden control color code
- Resistance: Good UV, chemical, and mechanical resistance, suitable for industrial environments
- Standards: DIN VDE 0295, IEC 60228, BS6360, RoHS & REACH compliant
Buy the MachFlex 375 SY – Reliable PVC Control Cables for Industrial Applications
Purchase the MachFlex 375 SY armored PVC control cable with galvanized steel wire braid shield online today. This high-quality control cable is designed for industry-grade control panels, machinery, and automation projects, offering excellent mechanical protection, chemical, UV resistance, and reliable performance up to 750 V. Suitable for fixed and occasional flexing installations, it ensures safety and durability in demanding environments. Order now and equip your control systems with dependable, UL-approved cable solutions available for quick online procurement.
Order your MachFlex 375 SY armored PVC control cable today and ensure your control systems operate with the highest reliability in demanding environments.
Frequently Asked Questions
Where can I buy Belden C7GBSYKC50?
You can click on the BUY or RFQ button to purchase C7GBSYKC50 from an authorized Belden distributor.
How do I troubleshoot issues or seek technical support for part C7GBSYKC50?
You can download the C7GBSYKC50 datasheet or visit the Belden website for support.
Who is the manufacturer of C7GBSYKC50?
Belden
