Bourns 4606X101153LF Conformal SIP Resistor Network
The Bourns 4606X-101-153LF is a conformal SIP (Single In-line Package) resistor network designed for a variety of applications requiring multiple resistors in a compact form factor. It utilizes thick film technology for reliable performance and is RoHS compliant, meeting environmental standards. The low profile design allows for compatibility with DIP (Dual In-line Package) layouts, providing design flexibility. Available in bulk and ammo-pak packaging, this network is suitable for applications such as DRAM, SCSI, and R/2R ladder networks.
Bourns 4606X101153LF Conformal SIP Resistor Network Specifications:
- Resistance Range: 10 ohms to 10 megohms
- Maximum Operating Voltage: 100 V
- Temperature Coefficient of Resistance: ±100 ppm/°C (below 50 Ω), ±250 ppm/°C (above 2.2 megohms)
- Resistance Tolerance: See circuits
- Insulation Resistance: 10,000 megohms minimum
- Dielectric Withstanding Voltage: 200 VRMS
- Operating Temperature: -55 °C to +125 °C
- Short Time Overload: ±0.25 %
- Load Life: ±1.00 %
- Moisture Resistance: ±0.50 %
- Resistance to Soldering Heat: ±0.50 %
- Terminal Strength: ±0.25 %
- Thermal Shock: ±0.25 %
- Flammability: Conforms to UL94V-0
- Body Material: Epoxy resin
- Standard Packaging: Bulk, Ammo-pak available
- Model: 46 = Conformal SIP, X = Thick Film Low Profile, 101 = Bussed, 102 = Isolated, 104 = Dual Terminator
- Features: Marking on contrasting background, RoHS compliant, low profile compatible with DIPs, wide assortment of pin packages, ammo-pak packaging, recommended for rosin flux and solvent clean processes
- Maximum package length: equal to 2.54mm (.100") times the number of pins, less .005mm (.002")
- Governing dimensions: metric, dimensions in parentheses are inches and are approximate
- Terminal centerline to centerline measurements: made at point of emergence of the lead from the body
Buy the 4606X-101-153LF BOURNS Conformal SIP Resistor Network | myMectronic
Purchase the Bourns 4606X-101-153LF conformal SIP resistor network securely and reliably online.
Buy Now
Frequently Asked Questions
Where can I buy Bourns 4606X101153LF?
You can click on the BUY or RFQ button to purchase 4606X101153LF from an authorized Bourns distributor.
How do I troubleshoot issues or seek technical support for part 4606X101153LF?
You can download the 4606X101153LF datasheet or visit the Bourns website for support.
Who is the manufacturer of 4606X101153LF?
Bourns
