Bourns 4816P1101LF SMD Trimming Potentiometer
The Bourns 4816P-1-101LF is a compact, surface mount trimming potentiometer ideal for applications requiring precise resistance adjustment. Its AEC-Q200 qualification ensures suitability for automotive environments, while RoHS compliance aligns with environmental regulations. The potentiometer's standard E.I.A. package facilitates automated assembly, and custom circuit configurations are available to address unique design requirements. It finds use in various applications including DRAM, R/2R ladder networks, and SCSI systems.
Bourns 4816P1101LF SMD Trimming Potentiometer Specifications:
- Resistance Range: 10 ohms to 2.2 megohms
- Maximum Operating Voltage: 50 V
- Temperature Coefficient of Resistance: ±100 ppm/°C (50 Ω and above), ±250 ppm/°C (below 50 Ω)
- TCR Tracking: 50 ppm/°C max. (for values > 50 Ω), 100 ppm/°C (for values ≤ 50 Ω)
- Operating Temperature: -55 °C to +125 °C
- Insulation Resistance: 10,000 megohms min.
- Dielectric Withstanding Voltage: 200 VRMS
- Flammability: Conforms to UL94V-0
- Lead Frame Material: Copper, solder coated
- Body Material: Thermoplastic
- Power Rating per Resistor (1 Circuit at 70 °C): 0.160 watt
- Power Rating per Resistor (2 Circuit at 70 °C): 0.080 watt
- Power Rating per Resistor (4 Circuit at 70 °C): 0.160 watt
Buy the 4816P-1-101LF BOURNS SMD Trimming Potentiometer | myMectronic
Securely purchase the Bourns 4816P-1-101LF and ensure reliable performance in your critical applications.
Buy Now
Frequently Asked Questions
Where can I buy Bourns 4816P1101LF?
You can click on the BUY or RFQ button to purchase 4816P1101LF from an authorized Bourns distributor.
How do I troubleshoot issues or seek technical support for part 4816P1101LF?
You can download the 4816P1101LF datasheet or visit the Bourns website for support.
Who is the manufacturer of 4816P1101LF?
Bourns
