Bourns CRL0805FWR470ELF Low-Value Chip Resistor
The CRL0805 series is a low-value chip resistor designed for high-reliability electronic circuits. It features RoHS compliance, resistance values ranging from 0.02 to 9.10 ohms, and tolerances of 1% or 5%. Available in multiple package sizes, including 0603, 0805, 1206, 2010, and 2512, these resistors operate within a temperature range of -55°C to +125°C. They are suitable for surface-mount applications requiring precise and stable resistance with high power ratings up to 1 watt. Packaging options include tape and reel for automated assembly.
Bourns CRL0805FWR470ELF Low-Value Chip Resistor Specifications:
- Resistance range: 0.02 to 9.10 ohms
- Tolerance: 1% or 5%
- Power Rating: up to 1 watt at 70°C
- Operating Temperature Range: -55°C to +125°C
- Resistance Coefficient: 0.052<R<9.12 ±200 PPM/°C, 0.022<R<0.052 ±400 PPM/°C, R=0.02Q ±600 PPM/°C
- Package Sizes: 0603, 0805, 1206, 2010, 2512
- Packaging: Tape and reel, 4,000 to 5,000 pcs per reel
- RoHS compliant
- Material: Metal film resistor with tin-plated termination
- Maximum Working Voltage varies with resistance and size
- Dimensions vary by package size, ranging from approximately 1.6 mm to 6.3 mm in length
- Temperature Coefficient: 0.052<R<9.12 ±200 PPM/°C
- Suitable for surface-mount technology
- Environmental withstand: Short time overload, thermal shock, resistance to soldering heat, and high temperature endurance
Buy the Bourns Series CRL Low-Value Chip Resistor: CRL0805FWR470ELF
Purchase the Bourns Series CRL0805FWR470ELF low-value chip resistor online today to benefit from RoHS compliance, high power ratings, and precise resistance values. This surface-mount component features resistance from 0.02 to 9.10 ohms, with 1% or 5% tolerance options, suitable for demanding electronic applications. Available in multiple package sizes, it offers excellent thermal stability, environmental resistance, and easy tape and reel packaging for automated assembly. Secure your supply of reliable, high-performance resistors and enhance your circuit designs effortlessly.
Order your Bourns Series CRL0805FWR470ELF low-value resistor today and ensure high reliability and performance in your electronic circuits.
Frequently Asked Questions
Where can I buy Bourns CRL0805FWR470ELF?
You can click on the BUY or RFQ button to purchase CRL0805FWR470ELF from an authorized Bourns distributor.
How do I troubleshoot issues or seek technical support for part CRL0805FWR470ELF?
You can download the CRL0805FWR470ELF datasheet or visit the Bourns website for support.
Who is the manufacturer of CRL0805FWR470ELF?
Bourns
