Bourns SRP0320R47K Power Inductor
The Bourns SRP0320 Series is a shielded power inductor designed for high saturation current and low buzz noise applications. Featuring a metal alloy powder core, flat wire construction, and RoHS compliance, it's ideal for power management and interference reduction in electronic circuits. The series offers various inductance values ranging from 0.47 µH to 7.00 µH, with operating temperature ranges from -40°C to +125°C. Its compact dimensions and high current handling capabilities make it suitable for use in various industrial, automotive, and consumer electronic applications, ensuring reliable performance and durability.
Bourns SRP0320R47K Power Inductor Specifications:
- Inductance: 0.47 µH to 7.00 µH
- Core Material: Metal alloy powder
- Operating Temperature: -40°C to +125°C
- Temperature Rise: Included in operating range
- Rated Voltage: 50 V
- Saturation Current (Isat): Up to 14.6 A depending on model
- DCR: Varies per model, around 12.0 mΩ to 156.0 mΩ
- Dimensions: Approximately 3.10 x 3.70 x 2.02 mm
- RoHS compliant and halogen free
- Soldering Profile: Max temperature 260°C, duration 30 sec
- Storage Temperature: -40°C to +125°C
- Moisture Sensitivity Level: 1
- ESD Classification: N/A
- Packaging: 2,500 pcs per reel with cover tape
Buy the Bourns Series SRP Shielded Power Inductor: SRP0320R47K
Discover the reliable and high-performance Bourns Series SRP Shielded Power Inductor, ideal for power supplies and interference filtering. This compact, RoHS-compliant indutor features a metal alloy powder core and flat wire construction, ensuring high saturation current and low buzz noise. Suitable for industrial, automotive, and consumer electronics, it operates efficiently across a wide temperature range from -40°C to +125°C. With various inductance options, it provides excellent thermal performance, durability, and easy integration for your advanced power circuits. Buy online now for fast delivery and optimal circuit performance.
Order your Bourns Series SRP0320R47K high-current shielded power inductor today and enhance your power management designs with proven reliability.
Frequently Asked Questions
Where can I buy Bourns SRP0320R47K?
You can click on the BUY or RFQ button to purchase SRP0320R47K from an authorized Bourns distributor.
How do I troubleshoot issues or seek technical support for part SRP0320R47K?
You can download the SRP0320R47K datasheet or visit the Bourns website for support.
Who is the manufacturer of SRP0320R47K?
Bourns
