Bourns SRP04101R0K Power Inductor
The power inductor series offers shielded construction with a metal alloy powder core, high saturation current, and low buzz noise. Designed with flat wire, these inductors comply with RoHS and halogen-free standards, providing reliable performance for high-current applications. Suitable for use in power supplies and electronic circuits, they feature an operating temperature range from -40°C to +125°C, peak temperature handling up to 260°C during soldering, and a rated voltage of 50V. The SRP0410 series ensures minimal energy loss and consistent inductance across various industrial applications.
Bourns SRP04101R0K Power Inductor Specifications:
- Core Material: Metal alloy powder
- Wire Material: Enamelled copper
- Terminal Finish: Sn
- Operating Temperature: -40°C to +125°C
- Peak Soldering Temperature: 260°C with max 30 sec. hold
- Rated Voltage: 50V
- Inductance Range: 0.47 µH to 10 µH
- Q Factor: 10 at 100 kHz/1V
- SRF: Varies per model, typical around 29-350 MHz
- Dimensions: Approx. 4.1 mm length, 4.7 mm width, 4.5 mm height
- Moisture Sensitivity Level: 1
- RoHS & Halogen Free: Yes
Buy the Bourns Series SRP0410 Power Inductor: SRP04101R0K
Enhance your electronic designs with Bourns Series SRP0410 power inductors, offering high saturation current, shielded construction, and RoHS compliance. Perfect for power supplies and industrial circuits, these inductors provide reliable performance across a wide temperature range from -40°C to +125°C. Featuring a maximum soldering temperature of 260°C with a short, controlled duration, they ensure safe and proper assembly. With compact dimensions and excellent electrical characteristics, installing these inductors guarantees energy efficiency, minimal noise, and long-term stability for demanding industrial applications. Purchase online now for quick delivery and superior quality.
Order your Bourns Series SRP0410 power inductors today and enhance the durability and efficiency of your industrial power projects.
Frequently Asked Questions
Where can I buy Bourns SRP04101R0K?
You can click on the BUY or RFQ button to purchase SRP04101R0K from an authorized Bourns distributor.
How do I troubleshoot issues or seek technical support for part SRP04101R0K?
You can download the SRP04101R0K datasheet or visit the Bourns website for support.
Who is the manufacturer of SRP04101R0K?
Bourns
