Bourns SRP05204R7K Power Inductor
The Bourns SRP0520 Series is a shielded power inductor designed for high performance applications. Featuring a metal alloy powder core, it offers high saturation current, low buzz noise, and RoHS compliance. These inductors are suitable for high-frequency power circuits, providing reliable inductance with flat wire construction and robust thermal characteristics. Ideal for use in switch-mode power supplies, DC-DC converters, and various electronic applications requiring precise inductance and high current capacity, they ensure long-lasting durability and efficient energy management.
Bourns SRP05204R7K Power Inductor Specifications:
- Inductance: 0.47µH to 10µH
- Maximum DC Resistance (DCR): 25.2mΩ to 2.52Ω depending on model
- Current rating (Irms): 12.5A to 152A
- Saturation current (Isat): 20.0A to 150A
- Operating temperature: -40°C to +125°C
- Rated voltage: 50V
- Size: 5.80 x 5.40 x 4.00 mm (approximated)
- Materials: Metal alloy powder core, tin-plated terminals
- Flammability: UL 94V-0
- Moisture Sensitivity Level: Level 1
- RoHS compliance and halogen-free
- Peak reflow temperature: 260°C max
- Soldering profile includes max temperature 260°C for 30 sec, and time above 217°C for 60-150 sec.
Buy the Buy Bourns SRP0520 Series Power Inductor Part Number SRP05204R7K Online
Order the Bourns SRP0520 series power inductors online today for dependable performance in power supply, DC-DC converters, and electronic circuits. Engineered to deliver high saturation current, low DCR, and RoHS compliance, these shielded inductors ensure durability and high efficiency. Their flat wire construction and high-quality materials provide excellent thermal stability and low noise operation. Ideal for demanding electronics applications, they guarantee long-term reliability, easy installation, and compliance with industry standards. Purchase online now for fast delivery and consistent quality.
Get Bourns SRP0520 PartNumber SRP05204R7K today—designed for high current capacity, RoHS compliance, and long-lasting reliability.
Frequently Asked Questions
Where can I buy Bourns SRP05204R7K?
You can click on the BUY or RFQ button to purchase SRP05204R7K from an authorized Bourns distributor.
How do I troubleshoot issues or seek technical support for part SRP05204R7K?
You can download the SRP05204R7K datasheet or visit the Bourns website for support.
Who is the manufacturer of SRP05204R7K?
Bourns
