Bourns SRP06101R0K Power Inductor
These shielded power inductors feature a metal alloy powder core, high saturation current, low buzz noise, and flat wire construction, ensuring reliable performance in power supply circuits and other industrial applications. Certified RoHS compliant and halogen-free, they offer excellent electrical characteristics at 25°C with a wide operating temperature range from -40°C to 125°C. Designed with enameled copper wire and tin-plated terminals, these inductors accommodate recommended current ratings and device-specific performance needs, making them suitable for demanding electronic systems requiring high-quality power management components.
Bourns SRP06101R0K Power Inductor Specifications:
- Core Material: Metal alloy powder
- Wire Material: Enameled copper
- Terminal Finish: Sn (tin plated)
- Temperature Range: -40°C to 125°C
- Soldering Peak Temperature: 260°C max
- Soldering Time Above 217°C: 60-150 sec max
- Inductance Range: 0.47 µH to 10 µH
- Q at 100 kHz/1V: 10
- SRF: 20 MHz to 240 MHz depending on model
- Dc Resistance: 1.5 to 25.2 mΩ
- Rated Current: varies by model from 1A to 25.2A
- Isat: 1 to 47 A depending on model
- Dimensions: 6.7 x 7.1 x 3.0 mm
- Packaging: 2500 pcs per reel
Buy the Bourns SRP0610 – Reliable Power Inductors for Industrial Applications
Secure your Bourns SRP0610 series power inductor online today to benefit from high saturation current, RoHS compliance, and robust construction. Perfect for industrial power supply designs, they provide reliable inductance, thermal stability, and efficient energy transfer. Whether designing high-current circuits or upgrading existing systems, these inductors deliver proven performance. Purchase from a trusted source and ensure your project benefits from top-quality power management components with fast delivery and expert support. Optimize your power systems now with Bourns.
Order your Bourns Series SRP0610 high-current power inductor today and enhance your power supply efficiency with quality components designed for demanding industrial projects.
Frequently Asked Questions
Where can I buy Bourns SRP06101R0K?
You can click on the BUY or RFQ button to purchase SRP06101R0K from an authorized Bourns distributor.
How do I troubleshoot issues or seek technical support for part SRP06101R0K?
You can download the SRP06101R0K datasheet or visit the Bourns website for support.
Who is the manufacturer of SRP06101R0K?
Bourns
