Bourns SRP06106R8K Power Inductor
The Bourns SRP0610 Series shielded power inductors are designed for high saturation current and low buzz noise, suitable for power management applications. Constructed with shielded design, metal alloy powder core, flat wire, and RoHS compliance, these inductors are halogen free and built for reliability. They feature detailed electrical specifications at 25°C, including inductance, Q factor, SRF, and current ratings. Dimensions for mounting and recommended layout are included, supporting operation from -40°C to +125°C and with a rated voltage of 50V, making them ideal for industrial and power electronics. They comply with safety and environmental standards and are supplied in reel packaging for easy automated placement.
Bourns SRP06106R8K Power Inductor Specifications:
- Core Material: Metal alloy powder
- Wire Material: Enameled copper
- Terminal Finish: Sn
- Inductance Range: 0.47 µH to 10.0 µH
- Q Factor: 10 to 49
- Self-Resonant Frequency: 20 MHz to 240 MHz
- DC Resistance: 1.52 mΩ to 2.52 mΩ
- Rated Current: 1 A to 25.2 A
- Maximum Operating Temperature: -40°C to +125°C
- Dimensions: Length 6.70 mm, Width 8.10 mm, Height 3.00 mm
- Packaging: 2500 pcs per reel, tape and reel packaging
- Peak Soldering Temperature: 260°C Max for 30 seconds
- Compliance: RoHS 2015/863, Halogen free, UL Recognized
Buy the Buy Bourns SRP0610 Series Power Inductor Part Number SRP06106R8K Online
Purchase Bourns SRP0610 Series Power Inductor online for reliable high saturation current performance and low noise operation. These shielded inductors feature RoHS compliance, halogen-free materials, and a rugged construction suitable for industrial, power supply, and electronic applications. With detailed electrical specifications like inductance, Q factor, SRF, and current ratings at 25°C, they support operation from -40°C to +125°C and have a rated voltage of 50V. The reel packaging ensures easy automation, making it convenient to source high-quality inductors for your electronics needs.
Get Bourns SRP06106R8K today—built for high saturation current and long-lasting durability in power management applications.
Frequently Asked Questions
Where can I buy Bourns SRP06106R8K?
You can click on the BUY or RFQ button to purchase SRP06106R8K from an authorized Bourns distributor.
How do I troubleshoot issues or seek technical support for part SRP06106R8K?
You can download the SRP06106R8K datasheet or visit the Bourns website for support.
Who is the manufacturer of SRP06106R8K?
Bourns
