C&K COMPONENTS 2TMA154 Datasheet & Stock

The SnapAction Small & Mini Microswitch features a contact rating ranging from low levels up to 21 amps at 277 V AC. It has an electrical life of approximately 300,000 cycles at 10 amps and 250 V AC. The switch offers an insulation resistance of at least 1,000 megaohms and a dielectric strength of a minimum of 1,500 volts RMS at sea level. It operates effectively within temperatures from -40°F to 185°F (-40°C to 85°C). The operating force is adjustable between 15 to 400 grams, typically with an actuator button. Mounting requires torque screws tightened to 2-5 in/lbs.
