C&K COMPONENTS 613802263 Miniature Switch
The C&K 7000 Series miniature switches feature versatile rocker and lever handles with various actuation and termination options. Built with durable materials like nylon, spring steel, and brass, these switches support multiple configurations including single, double, and triple pole functions. Designed for panel mounting with snap-in, rear, or front options, they are ideal for industrial, medical, and telecommunication applications. They offer RoHS compliance, epoxy terminal seals, and operate within -30°C to 85°C, ensuring reliable performance in demanding environments. Dimensional details specify panel thickness compatibility from 0.047
C&K COMPONENTS 613802263 Miniature Switch Specifications:
- Contact Rating: 0.4 VA max @ 20 V AC/DC, 5A @ 120 V AC/DC, 2A @ 250 V AC
- Electrical Life: 100,000 cycles for models U15, UX1; 40,000 cycles others
- Contact Resistance: <10 mΩ initial @ 2-4 VDC, 100 mA
- Insulation Resistance: ≥10^9 Ω
- Dielectric Strength: ≥1000 V rms
- Operating Temperature: -30°C to 85°C
- Materials: Case – Nylon 6/6 or DAP, Actuator – Nylon, Frame – Nylon/Steel, Bushing – Brass/Nickel
- Terminal Seal: Epoxy, Hardware: Brass, Stainless Steel
- Mounting Options: Snap-in, rear, front, with panel thickness compatibility from 0.047 to 0.125 inches
Buy the C&K Series 7000 Wall Mount Switch: 613802263
Get your C&K Series 7000 miniature switch online today for excellent reliability and versatile mounting options. Perfect for industrial, medical, and telecommunication environments, these switches are RoHS compliant, supported by epoxy terminal seals, and made from durable materials like nylon and brass. Operating within -30°C to 85°C, they provide up to 100,000 cycles of life with low contact resistance. Easily integrate into panel systems with snap-in, rear, or front mounting, ensuring seamless performance in demanding projects.
Order your C&K Series 7000 wall mount switch today and ensure reliable, durable, and versatile control solutions for your industrial applications.
Frequently Asked Questions
Where can I buy C&K COMPONENTS 613802263?
You can click on the BUY or RFQ button to purchase 613802263 from an authorized C&K COMPONENTS distributor.
How do I troubleshoot issues or seek technical support for part 613802263?
You can download the 613802263 datasheet or visit the C&K COMPONENTS website for support.
Who is the manufacturer of 613802263?
C&K COMPONENTS
