C&K COMPONENTS C1015 F Series Pushbutton Switch
The C&K C1015 F Series Pushbutton Switch is a versatile modular solution designed for a wide range of industrial applications. Its modular design allows for customization with up to 10 poles per module and a variety of contact terminals to meet specific requirements. The switch features flexible mounting and switch ganging configurations, making it suitable for audio selection, digital equipment interfaces, and medical equipment interfaces. Constructed with durable materials like polycarbonate, polyester, and brass with silver and gold plating, the C1015 ensures reliable performance and longevity. It is RoHS compliant and compatible, offering a secure and efficient solution for various control and switching needs.
C&K COMPONENTS C1015 F Series Pushbutton Switch Specifications:
- Switching Power: F module max. AC/DC: Silver: 50 VA/15W, Gold: 1 VA/300 mW
- Switching Voltage: F module max. AC/DC: Silver: 125/30V, Gold: 50/30 V
- Switching Current: F module max. AC/DC: Silver: 0.5A/0.5A, Gold: 0.04A/0.01A
- Carrying Current: Max at du = 20C: Silver: < 2A, Gold: <0.5A
- Dielectric Strength: (50 Hz, 1 min.): Chassis/contact: ^1500V Between contacts: ^1500V
- Operating Life OA/EE: >10[5] operations (24V/200mA)
- Operating Life GR: >3.5 x 10[4] operations
- Contact Resistance: Initial: Typical %10 mΩ, max. 20 mΩ After operating life: %100 mΩ
- Insulation Resistance: ^10[9] Ω between open contacts, ^10[9] Ω between chassis and contacts
- Capacitance: %0.7 pF between 2 contacts (at f = 10 kHz)
- Total Travel/Latching Travel: 4.7mm/3.3mm (.185 inch/.130 inch)
- Typical Operating Force 2U: 6.5N (650 grams)
- Typical Operating Force 4U: 6.5N (650 grams)
- Typical Operating Force 6U: 7.5N (750 grams)
- Typical Operating Force 8U: 9.0N (900 grams)
- Typical Operating Force 10U: 9.0N (900 grams)
- European Typical Operating Force 2U: 3.5N±0.5N (350 grams±100 grams)
- European Typical Operating Force 4U: 5N±1N (500 grams±100 grams)
- European Typical Operating Force 6U: 6.5N±1N (650 grams±100 grams)
- European Typical Operating Force 8U: 9.0N±1N (900 grams±100 grams)
- Operating Temperature Range: -40˚C to 70˚C
- Housing Material: Polycarbonate UL 94V-0 or polyester UL 94V-0
- Actuator Material: Polyester UL 94V-0
- Movable Contact Material: Bimetal brass, silver plated, gold plate over nickel
- Stationary Contact & Terminal Material: Brass, silver plated, gold plated
- Terminal Board Material: Polyester UL 94V-0
- Return Spring Material: Music wire
- Terminal Seal Material: RTV adhesive sealant
- Chassis Material: Steel
- Lockout Pin Material: Steel
- Blocker Material: Steel
