C&K COMPONENTS C1153662776 Space Splice Connector
The C&K COMPONENTS Space Splice connector provides a reliable and standardized solution for linking two wires. Utilizing D*MA crimpable contact technology, this connector offers easy usability and a compact design suitable for a range of cable gauges (AWG 20 to AWG 30). It's particularly well-suited for space applications due to its low residual magnetism, low degassing, and high radiation and temperature resistance (PEEK material). The connector replaces manual splices, offering a more consistent and efficient connection method. It finds applications in satellite structures, payloads, harnesses, laboratory equipment, avionics, military, and medical devices.
C&K COMPONENTS C1153662776 Space Splice Connector Specifications:
- Operating Temperature: –55 / +125 °C
- Storage Temperature: –65 / +125 °C
- Working Voltage: 300 Vrms
- Voltage Proof Leakage Current: 1250 Vrms
- Insulator Resistance: 5000 MΩ min.
- Maximum Rated Current: 7.5 A
- Contact Resistance: 5 mΩ
- Residual Magnetism Level: < 200 Gamma
- Radiation Resistance: > 1 x 108 Rads
- Contact Insertion Withdrawal Force (1st contact): < 18.5 N
- Contact Insertion Withdrawal Force (2nd contact): < 21.8 N
- Contact Retention: 40 N max.
- Weight: 0.2gr max.
- Insulator Material: PEEK, UL 94-V0
- Clip Material: Beryllium Copper Alloy
- Socket Contact Material: Copper Alloy, 1.27µm Gold over Copper underlayer
- Pin Contact Material: Copper Alloy, 1.27µm Gold over Copper underlayer
- Dimensions: 29.50mm, ∅ 3mm
