C&K COMPONENTS D6C90F2LFS Switch
The D6C series is a SPST momentary key switch featuring a durable square black actuator for reliable switching in electronic applications. It offers positive tactile feedback and easy X and Y PCB coding, making it ideal for video equipment, gaming devices, and household appliances. The switch supports high-temperature operation, with flexible mounting options and various models, including illuminated versions with LED indicators. With robust electrical and mechanical specifications, it ensures long service life and dependable performance under demanding conditions, suitable for diverse industrial and consumer electronic uses.
C&K COMPONENTS D6C90F2LFS Switch Specifications:
- Contact Arrangement: 1 make contact (SPST), NO
- Operating Force: 1.3N (Standard), 2.5N (Button options)
- Travel: 0.2 mm to 1.0 mm depending on model
- Sealing Class: IP40
- Operating Temperature: -20°C to 85°C
- Switching Power Max: 3 VA non-illuminated, 0.35 VA illuminated
- Switching Voltage Max: 32 VDC non-illuminated, 35 VDC illuminated
- Switching Current Max: 100 mA DC non-illuminated, 10 mA DC illuminated
- Electrical Life: Up to 250,000 operations for version F1
- Contact Resistance: <100 mΩ non-illuminated, <200 mΩ illuminated
- Dielectric Strength: 250V (1 minute)
- Insulation Resistance: 210 MΩ
- Soldering Profile: Wave soldering compatible, hand soldering at 350°C for 3 seconds
- Dimensions: Compact form with 12.7 mm center distance, PCB mounting with PC pins
Buy the Buy Electron Switches SPST Momentary Key Switch Part Number D6C90F2LFS Online
Discover the high-quality SPST momentary key switch ideal for electronic devices, gaming, and household appliances. The D6C series offers tactile feedback, high-temperature resistance, and long service life. Available in black non-illuminated versions, it features easy PCB mounting, compact dimensions, and reliable electrical performance up to 250,000 cycles. Perfect for various industrial and consumer electronic projects, ensuring dependable operation in demanding environments. Order online today for quick delivery and trusted performance.
Buy Electron Switches D6C90F2LFS now and experience unmatched reliability and performance in your electronic control applications.
Frequently Asked Questions
Where can I buy C&K COMPONENTS D6C90F2LFS?
You can click on the BUY or RFQ button to purchase D6C90F2LFS from an authorized C&K COMPONENTS distributor.
How do I troubleshoot issues or seek technical support for part D6C90F2LFS?
You can download the D6C90F2LFS datasheet or visit the C&K COMPONENTS website for support.
Who is the manufacturer of D6C90F2LFS?
C&K COMPONENTS
