C&K COMPONENTS E221SD1AGE Sealed Snap-acting Pushbutton Switch
The C&K E020 Series Sealed Snap-acting Momentary Pushbutton Switches offer a robust solution for applications requiring a sealed environment. These switches feature a long-life contact design and are available in various configurations to meet specific needs. They are process sealed to withstand machine soldering temperatures and pressure wash cleaning methods, making them ideal for demanding industrial environments such as telecommunications equipment, computers, and instrumentation. The switches are RoHS compliant and offer a reliable connection with options for PC thru-hole or snap-in mounting.
C&K COMPONENTS E221SD1AGE Sealed Snap-acting Pushbutton Switch Specifications:
- Contact Rating: 0.4 VA max. @ 20 V AC or DC (B contact material) or 1 AMP @120 V AC or 28 V DC (G contact material)
- Case & Bushing: Glass filled nylon 6/6, flame retardant (UL 94V-0)
- Plunger: Glass filled nylon or glass filled polyester (PBT) (UL 94V-0)
- Switch Support: Brass or steel, matte-tin
- Switch Support Retainer: Stainless steel
- Electrical Life: 60,000 make-and-break cycles at full load
- N.O. & N.C. Contacts (EX25 Models): Copper alloy, with gold plate over nickel plate
- N.O. & N.C. Contacts (EX21 Models): Coin silver, with gold plate over nickel plate
- Contact Resistance: Below 50 mΩ typ. initial @ 2–4 V DC, 100 mA
- Insulation Resistance: 10[9] Ω min.
- Dielectric Strength: 1000 Vrms min. @ sea level
- Common Contacts & All Terminals: Copper alloy, with gold plate over nickel plate
- Operating Temperature: –30ºC to 75ºC
- Cap Installation Force: 10 lbs. max. permissible
- Terminal Seal: Epoxy
- Solderability: Per MIL-STD-202F method 208D or EIA RS-186E method 9 (1 hour steam aging)
- Disposable Boot: Vinyl splashproof boot supplied standard
Buy the E221SD1AGE C&K COMPONENTS Sealed Snap-acting Pushbutton Switch | myMectronic
Purchase the C&K E221SD1AGE Sealed Snap-acting Pushbutton Switch securely and reliably online.
Buy Now
Frequently Asked Questions
Where can I buy C&K COMPONENTS E221SD1AGE?
You can click on the BUY or RFQ button to purchase E221SD1AGE from an authorized C&K COMPONENTS distributor.
How do I troubleshoot issues or seek technical support for part E221SD1AGE?
You can download the E221SD1AGE datasheet or visit the C&K COMPONENTS website for support.
Who is the manufacturer of E221SD1AGE?
C&K COMPONENTS
