C&K COMPONENTS LP02C11T203DQ Miniature Slide Switch
The C&K COMPONENTS LP02C11T203DQ is a miniature snap-in slide switch offering a compact and reliable solution for switching applications. Designed with a 6/6 nylon housing and glass-filled acetal actuator, it provides durability and resistance to UV and petroleum exposure. The switch is available with various contact materials, including silver and gold plating, catering to different current and voltage requirements. Its snap-in mounting style simplifies integration into various systems, making it ideal for small appliances, outdoor equipment, and portable tools. The switch is RoHS compliant, ensuring environmental responsibility.
C&K COMPONENTS LP02C11T203DQ Miniature Slide Switch Specifications:
- Contact Rating: Q contact material (LP0X, LP2X Models: 6 AMPS @ 125 V AC or 28 V DC; 3 AMPS @ 250 V AC (UL/CSA). LP7X, LP8X Models: 11 AMPS @ 125/250 V AC (UL/CSA))
- Electrical Life: 10,000 make-and-break cycles at full load
- Insulation Resistance: 10[9] Ω min.
- Dielectric Strength: 1,000 Vrms min. @ sea level
- Contact Resistance: Below 10 m Ω typ. initial @ 2-4 V DC, 100 mA
- Housing Material: 6/6 nylon (UL94V-2), black
- Actuator Material: Glass filled acetal, UV and petroleum resistant, black
- Contact Material: Copper, silver plated (Q contact material)
- Terminal Material: Copper, silver plated
- Terminal Seal: Epoxy
- Operating Temperature: -30ºC to +65ºC
- Storage Temperature: -30ºC to +85ºC
- Mounting Style: Snap-in panel with tabs (T2)
- Panel Thickness: .030–.120 inches
Buy the LP02C11T203DQ C&K COMPONENTS Miniature Slide Switch | myMectronic
Securely purchase the C&K COMPONENTS LP02C11T203DQ miniature slide switch online for your industrial needs.
Buy Now
Frequently Asked Questions
Where can I buy C&K COMPONENTS LP02C11T203DQ?
You can click on the BUY or RFQ button to purchase LP02C11T203DQ from an authorized C&K COMPONENTS distributor.
How do I troubleshoot issues or seek technical support for part LP02C11T203DQ?
You can download the LP02C11T203DQ datasheet or visit the C&K COMPONENTS website for support.
Who is the manufacturer of LP02C11T203DQ?
C&K COMPONENTS
