C&K COMPONENTS S802C21S207Q DPDT Slide Switch
The C&K COMPONENTS S802C21S207Q is a robust DPDT slide switch suitable for a wide range of applications, including portable tools, small appliances, and floor care products. It boasts a durable nylon housing and offers both PC and snap-in panel mounting options for versatile integration. The switch is designed to meet RoHS compliance standards, ensuring environmentally responsible usage. With a 15-amp rating at 125V AC and a reversing option, the S802C21S207Q provides reliable switching functionality for various industrial and consumer applications. Its robust construction and multiple mounting options make it a dependable choice for demanding environments.
C&K COMPONENTS S802C21S207Q DPDT Slide Switch Specifications:
- Contact Rating: 6 AMPS @ 125 V AC; 6 AMPS @ 250 V AC; 1 AMP @ 125 V DC (S1XX, S2XX Models); 12 AMPS @ 125 V AC; 6 AMPS @ 250 V AC; 1 AMP @ 125 V DC (S5XX, S6XX Models); 15 AMPS @ 125 V AC; 6AMPS @ 250 V AC (S7XX, S8XX Models)
- Housing Material: 6/6 nylon (UL94V-2), black
- Top Plate Material: 6/6 nylon (UL94V-2), black
- Actuator Material: 6/6 nylon (UL94V-2), black (standard)
- Contact Material: Copper, silver plated (Q contact material)
- Terminal Material: Copper, silver plated (Q contact material)
- Electrical Life: 10,000 make-and-break cycles at full load
- Contact Resistance: Below 10 m Ω typ. initial
- Contact Spring: Music wire or stainless steel
- Insulation Resistance: 10[9] Ω min.
- Dielectric Strength: 1,000 Vrms min. @ sea level
- Operating Temperature: -30ºC to +65ºC
- Storage Temperature: -30ºC to +85ºC
- Mounting Options: PC and Snap-in panel mounting
- Switch Function: SPST, SPDT, DPDT
- Terminal Seal: Epoxy
Buy the S802C21S207Q C&K COMPONENTS DPDT Slide Switch | myMectronic
Purchase the C&K COMPONENTS S802C21S207Q DPDT Slide Switch securely and conveniently online.
Buy Now
Frequently Asked Questions
Where can I buy C&K COMPONENTS S802C21S207Q?
You can click on the BUY or RFQ button to purchase S802C21S207Q from an authorized C&K COMPONENTS distributor.
How do I troubleshoot issues or seek technical support for part S802C21S207Q?
You can download the S802C21S207Q datasheet or visit the C&K COMPONENTS website for support.
Who is the manufacturer of S802C21S207Q?
C&K COMPONENTS
