C&K COMPONENTS ZNE18FA200BKGN2UEEL DPDT Switch
This DPDT pushbutton switch features a round green actuator for reliable switching in various applications. Crafted with a silver-plated contact surface, it ensures excellent electrical conductivity and durability. The thermoplastic housing, rated UL 94 V-0 for flame resistance, provides ruggedness and safety. Designed with solder pin termination style for ease of installation, it supports a current of 6 A and voltage ratings of 250 VAC and 100 VDC, with a power capacity of 3 W. Suitable for through-hole mounting, it withstands up to 10,000 switching cycles, making it ideal for demanding control systems.
C&K COMPONENTS ZNE18FA200BKGN2UEEL DPDT Switch Specifications:
- Actuator Type: Round Green
- Switching Function: Double Pole Double Throw (DPDT)
- Contact Resistance: <10mΩ
- Insulation Resistance: >10^8 MΩ
- Dielectric Strength: >2.0kVAC
- Max Current Rating: 6A
- Voltage Ratings: 250VAC, 100VDC
- Power Rating: 3W
- Housing Material: Thermoplastic UL 94 V-0
- Mounting Style: Through-hole
- Switching Cycles: 10,000 minimum
- Terminations: Solder pins
- Operating Temperature: -20°C to +70°C
- Sealing: Not sealed
- Approval: UL Listed
Buy the Bulgin Series Switch: DPDT Round Green Actuator - Part Number ZNE18FA200BKGN2UEEL
Order the Bulgin DPDT switch with green actuator today from our online store. Designed for durability and precision, it features UL 94 V-0 flame-rated housing and silver-plated contacts. Perfect for demanding switching needs with a current rating of 6A and voltage capability of 250VAC, it supports 10,000 switching cycles. Easy to install via through-hole mounting with solder pins, ensuring secure connections. Elevate your control systems with this reliable, high-quality switch—available for fast online purchase and quick delivery.
Buy Bulgin DPDT switch with green actuator now and experience unmatched reliability and performance for your control applications.
Frequently Asked Questions
Where can I buy C&K COMPONENTS ZNE18FA200BKGN2UEEL?
You can click on the BUY or RFQ button to purchase ZNE18FA200BKGN2UEEL from an authorized C&K COMPONENTS distributor.
How do I troubleshoot issues or seek technical support for part ZNE18FA200BKGN2UEEL?
You can download the ZNE18FA200BKGN2UEEL datasheet or visit the C&K COMPONENTS website for support.
Who is the manufacturer of ZNE18FA200BKGN2UEEL?
C&K COMPONENTS
