CARLO GAVAZZI EC5525PPAP1 Capacitive Proximity Sensor
The Capacitive proximity sensor EC 5525 features TRIPLESHIELD™ sensor protection, adjustable sensing distances from 4-25 mm, and a compact polycarbonate IP 67 housing. It offers reliable make and break switching with a 200 mA DC output, suitable for detection of metallic and non-metallic objects in various industrial applications such as material handling, plastic, packaging, and ceramics. Easy to mount using two M4 screws, it provides high noise immunity, LED status indication, and configurable sensing range, making it an adaptable and durable choice for challenging environments.
CARLO GAVAZZI EC5525PPAP1 Capacitive Proximity Sensor Specifications:
- Rated operating distance: 4 to 25mm, factory set at 25 mm
- Effective operating distance: 0.9xS to 1.1xS
- Usable distance: 0.8xS to 1.2xS
- Repeat accuracy: <5%
- Hysteresis: 3 to 20% of sensing distance
- Rated operational voltage: 10-40 VDC, ripple included
- Rated operational current: <200 mA
- No-load current: <10 mA
- Degree of protection: IP 67
- Operating temperature: -25°C to +80°C
- Housing: Polycarbonate, Grey
- Connection: 2m PVC cable, M12 plug options
- Voltage drop: <2.5 VDC
- Approvals: UL, CSA, CE
Buy the Buy Carlo Gavazzi Capacitive Proximity Sensor Part Number EC5525PPAP1 Online
Purchase the Carlo Gavazzi EC 5525 capacitive proximity sensor online to benefit from high noise immunity, adjustable sensing range up to 25 mm, and IP 67 rated polycarbonate housing. Perfect for detecting non-metallic and metallic objects in material handling, packaging, ceramics, and plastic industries. Easy to install with mounting brackets and M4 screws, it offers reliable make-and-break switching, LED status indication, and flexible connection options including cable and plug versions. Ensure optimal performance in challenging environments with this durable, user-friendly sensor.
Buy Carlo Gavazzi EC 5525 proximity sensor now and experience reliable detection and rugged IP 67 polycarbonate housing for industrial environments.
